Description
Honeywell 45075504 Overview
The 500' red Genesis Series 18 AWG Plenum-Rated Fire Alarm Cable with 4 Solid Conductors from Honeywell comes packaged in a pull box. The cable offers a gauge size of 18 AWG. It is unshielded and features a Plenum-rated jacketing material.
UPC: 619172016513
In the Box
- Honeywell Genesis Series 18 AWG Plenum-Rated Fire Alarm Cable with 4 Solid Conductors (Red, 500' Pull Box)
- Limited 3-Year Manufacturer Warranty
Honeywell 45075504 Specs
Construction
| Gauge | 18 AWG |
| Conductors | 4 x Solid Bare Copper |
| Insulation | Plenum PVC Nominal Thickness: 0.007" / 0.178 mm |
| Lay Length | Nominal: 4.5" / 114.3 mm |
| Jacket | Plenum PVC Nominal Thickness: 0.015" / 0.381 mm |
| Outer Diameter | Nominal: 0.157" / 3.988 mm |
Properties
| Operating Voltage | Maximum: 300 V |
| DC Resistance | 6.52 Ohms at 1000' / 304.8 m at 68°F / 20°C |
| Capacitance | Nominal: 32.1 pF/ft |
| Nominal Impedance | 58 Ohms |
| Temperature Rating | -4 to 167°F / -20 to 75°C |
Certifications
| Flame Rating | NFPA 262 (Plenum), CSA C22.2 No. 2556 (FT6) |
| RoHS Compliant | Yes |
| Ratings | FPLP, CL3P, FT6 |
| Approvals | UL Listed |
Physical
| Length | 500' / 152.4 m |
| Weight | Not Specified by Manufacurer |
Packaging Info
| Package Weight | 14.6 lb |
| Box Dimensions (LxWxH) | 11.181 x 10.63 x 8.425" |
