The 500� long blue Genesis Series 16 AWG Unshielded Home Theater Sound Jacketed Cable with 2 Unpaired Conductors from Honeywell comes packaged in a pull box. The cable offers a gauge size of 16 AWG. It is unshielded and features a general-purpose jacketing material. It is your complete solution for high-end audio transmission, stereo, professional audio systems, and home theater systems.
The home theater cable features WaveFLEX flexible jacketing technology. WaveFLEX jacketing makes the cable easier to strip, improving performance, while reducing the likelihood of kinks and tearing braids or shielding. Incredibly flexible, the ridged jacketing makes termination a snap and is engineered to withstand the rigors of challenging installations, while maintaining full UL specifications. This saves you time and money, and enables you to move on to the next job more quickly.
- Countdown or sequential footage markings
- Twisted stranded bare copper conductors
- Polypropylene insulation
- Super flexible PVC jacket
- Sunlight resistant
- CM, CL2 listed
- UL Standards 13, & 444; NEC Article 725
- Flame Rating: UL 1685 Vertical Tray
UPC: 619172015530
In the Box
Honeywell Genesis Series 16 AWG Unshielded Home Theater Sound Jacketed Cable with 2 Unpaired Conductors (Blue, 500' Pull Box)
- Limited 3-Year Warranty on Parts & Labor
| Gauge | 16 AWG |
| Conductors | 2 bare copper conductors with 26 / 30 strand count |
| Insulation | Polypropylene
Nominal Thickness: 0.010" (0.254 mm)
Nominal Diameter: 0.078" (1.981 mm)
Colors: Black and red |
| Lay Length | Nominal: 3.0" (76.2 mm) |
| Jacket | PVC
Nominal Thickness: 0.017" (0.432 mm) |
| DC Resistance | 4.1 ?/m at 20�C |
| Nominal Capacitance | 22 pF/ft |
| Nominal Impedance | 70 ? |
| Pulling Tension | Maximum: 30.0 lb (13.6 kg)
Recommended: 22.5 lb (10.2 kg) The recommended pulling tension is 75% of the maximum value. |
| Temperature Rating | -4 to 140�F (-20 to 60�C) |
| Operating Voltage | Maximum: 300 V |
| Outer Diameter | Nominal: 0.192" (4.877 mm) |
| Length | 500.0' (152.4 m) |
| Weight | 27.0 lb per MFT (12.3 kg per MFT) |
| Packaging Info |
| Package Weight | 12.4 lb |
| Box Dimensions (LxWxH) | 11.0 x 10.6 x 8.3" |
