Description
The white Genesis General Communications UTP Cable comes in a 1000�(305m) reel-in-a box dispensing system. This cable is the main component of a communications system and a key determinant to its performance. It also adheres to TIA/EIA category requirements.
- 4-pair Category 6 unshielded twisted pair (UTP) cable
- Plenum communication (CMP) rated by UL
- AWG 23 solid bare copper conductors
- FEP insulation
- Fluoropolymer spacer
- LSPVC jacket with ripcord
- Sequential footage markings
- ETL verified to meet TIA/EIA-568-B.2-1 requirements
- Unshielded Twisted Pair
- Sunlight Resistant (except Plenum)
- Ripcord
In the Box
Honeywell Genesis General Communications UTP Cable (1000' Reel in-a-Box, White)
- Limited 1-Year Warranty
| Electrical Specifications | |
|---|---|
| Voltage Rating | 300 V |
| Current | Current Rating: 1.4 A |
| DC Resistance | Nominal Value: 7.6 ? / 100 m Maximum Value: 9.38 ? / 100m |
| Resistance | Resistance Unbalance: Nominal Value: 1.5% Maximum Value: 5% |
| Capacitance | Nominal Value: 4.9 nF/100m Maximum Value: 5.6 nF / 100m Capacitance Unbalance: Nominal Value: 50 pF / 100m Maximum Value: 330 pF/100m |
| Velocity of Propagation | Nominal Value: 70% |
| Propagation Delay | Nominal Value: 515 ns / 100m Maximum Value: 570 ns / 100m |
| Delay Skew (ns/100 m) | Nominal Value: 17 ns / 100m Maximum Value: 45 ns / 100m |
| Physical Specifications | |
|---|---|
| Style | 23/4pr Cat 6 CMP |
| Conductor | AWG 23 solid bare copper conductor |
| Insulation | FEP |
| Jacket | Jacket Type: LSPVC with ripcord Jacket Diameter: 0.240" (0.609 cm) |
| Minimum Bend Radius | 1.0" (2.5 cm) |
| Pull Strength | 25.0 lb (11.3 kg) |
| Cable Length | 1000.0'(304.8 m) |
| Weight | 28.0 lb (12.7 kg) |
