Description
The blue Honeywell Genesis Category 6 Unshielded Twisted Pair Plenum Communication Cable is a 1000' long cable that comes in a reel-in-a-box and is rated by UL and has #23 AWG solid bare copper conductors. It features FEP insulation, no spacer, a PVC jacket with ripcord under jacket and sequential footage markings. It is ETL Verified to TIA/EIA-568-B.2-1 requirements and sweep tested to 350 MHz.
- 4-Pair CAT6 Unshielded Twisted Pair (UTP) cable
- Plenum Communication (CMP) rated by UL
- #23 AWG solid bare copper conductor
- FEP insulation
- PVC jacket with ripcord under jacket
- Sequential footage markings
- ETL Verified to TIA/EIA-568-B.2-1 requirements and sweep tested to 350 MHz
UPC: 781410982529
In the Box
Honeywell Genesis Category 6 Unshielded Twisted Pair Plenum Communication Cable (Reel-in-a-Box, 1000', Blue)
- Limited 30-Year Warranty
| Type | 23/4PR CAT6 CMP |
| Voltage Rating | 300V |
| Current | 1.4A |
| DC Resistance | Nominal: 7.6 ohms/100m Maximum: 9.38 ohms/100m |
| Resistance | Unbalance: Nominal: 1.5% Maximum: 5% |
| Capacitance | Nominal: 4.9 nF/100m Maximum: 5.6 nF/100m Unbalance: Nominal: 50 pF/100m Maximum: 330 pF/100m |
| Velocity of Propagation | Nominal: 69% |
| Propagation Delay | Nominal: 535 ns/100m Maximum: 570 ns/100m |
| Delay Skew (ns/100 m) | Nominal: 20 ns/100m Maximum: 45 ns/100m |
| Cable Diameter | 0.2" (0.5 cm) |
| Insulation | FEP |
| Jacket | PVC jacket |
| Minimum Bend Radius | 1" (2.54 cm) |
| Pull Strength | 25 lbs (11.33 kg) |
| Cable Length | 1000' (304.8 m) |
| Weight | 25 lbs (11.33 kg) |
| Packaging Info | |
|---|---|
| Package Weight | 24.7 lb |
| Box Dimensions (LxWxH) | 12.0 x 12.0 x 10.5" |
Bulk Discount
| Quantity | Price |
| 2 | ₹ 83079.5 |
| 3-5 | ₹ 82231.75 |
| 5-10 | ₹ 80536.25 |
| 10+ | ₹ 78840.75 |
Bulk discount will be automatically applied during checkout based on quantity.
