Description
The blue Honeywell Genesis Category 6 Unshielded Twisted Pair Plenum Communication Cable is a 1000' long cable that comes in a reel-in-a-box and is rated by UL and has #23 AWG solid bare copper conductors. It features FEP insulation, a fluoropolymer spacer, a LSPVC jacket with a ripcord under its jacket and sequential footage markings. It is ETL Verified to TIA/EIA 568-B.2-1 requirements.
- 4-Pair CAT6 Unshielded Twisted Pair (UTP) cable
- Plenum Communication (CMP) rated by UL
- #23 AWG solid bare copper conductor
- FEP insulation
- LSPVC jacket with a ripcord under the jacket
- Sequential footage markings
- ETL verified to TIA/EIA 568-B.2-1 requirements
UPC: 619172071796
In the Box
Honeywell Genesis Category 6 Unshielded Twisted Pair Plenum Communication Cable (Reel-in-a-Box, 1000', Blue)
- Limited 30-Year Warranty
| Type | 23/4PR CAT6 CMP |
| Voltage Rating | 300V |
| Current | 1.4A |
| DC Resistance | Nominal: 7.6 ohms/100m Maximum: 9.38 ohms/100m |
| Resistance | Unbalance: Nominal: 1.5% Maximum: 5% |
| Capacitance | Nominal: 4.9 nF/100m Maximum: 5.6 nF/100m Unbalance: Nominal: 50 pF/100m Maximum: 330 pF/100m |
| Velocity of Propagation | Nominal: 70% |
| Propagation Delay | Nominal: 515 ns/100m Maximum: 570 ns/100m |
| Delay Skew (ns/100 m) | Nominal: 17 ns/100m Maximum: 45 ns/100m |
| Cable Diameter | 0.24" (0.6 cm) |
| Insulation | 100% FEP |
| Jacket | 23 Solid Bare Copper |
| Minimum Bend Radius | 1" (2.54 cm) |
| Pull Strength | 25 lbs (11.33 kg) |
| Cable Length | 1000' (304.8 m) |
| Weight | 28 lbs (12.7 kg) |
| Packaging Info | |
|---|---|
| Package Weight | 34.4 lb |
| Box Dimensions (LxWxH) | 14.4 x 13.6 x 13.5" |
