Hikvision DS-D5032QE Overview
Monitor the feed from your surveillance cameras with the black DS-D5032QE 31.5" LED-Backlit Surveillance Monitor from Hikvision. This unit displays video at a maximum resolution of 1920 x 1080 at 60 Hz. It features 178/178° H/V viewing angles, a 16:9 aspect ratio, and a 1400:1 contrast ratio. The monitor is equipped with built-in speakers, an RJ45/RS-232 interface, and HDMI, VGA, and audio inputs. VESA mount compliance offers flexible installation options.
16.7 million display colors
Auto signal input detection
Smart engine for phase, image position, and color calibration
CE, FCC, and cUL certified
In the Box
- Hikvision DS-D5032QE 31.5" LED-Backlit Surveillance Monitor
- Power Cord
- Remote Control with Battery
- Pedestal
Hikvision DS-D5032QE Specs
Display
Screen Size (Diagonal) |
31.5" |
Resolution |
1920 x 1080 |
Panel Type |
LCD |
Brightness |
300 cd/m² (Typical) |
Viewing Angle (H x V) |
178 x 178° |
Screen Area |
27.50 x 15.47" / 698.4 x 392.85 mm |
Aspect Ratio |
16:9 |
Contrast Ratio |
1400:1 |
Response Time |
8 ms |
Refresh Rate |
60 Hz |
Dot Pitch |
0.36375 x 0.36375 mm |
Backlighting Technology |
LED |
Connectivity
Primary Connectivity Location |
Display |
Input Ports |
1 x HDMI Video 1 x VGA 15-Pin Video 1 x 1/8" / 3.5 mm Audio |
Ethernet Ports |
1 |
Other I/O |
1 x RS-232C |
Bluetooth |
None |
General
Display Orientation |
Landscape |
Audio
Built-In Speakers |
Yes, 2 x 5 W |
Speaker Configuration |
2-Channel |
Electrical
Power Consumption |
Typical: < 55.0 W Standby: < 0.5 W |
AC Input Power |
100 to 240 VAC, 50 / 60 Hz |
Power Adapter Type |
External |
Environmental
Operating Temperature |
41 to 104°F / 5 to 40°C |
Storage Temperature |
-4 to 140°F / -20 to 60°C |
Operating Humidity |
20 to 80% |
Storage Humidity |
10 to 90% |
Certifications |
CE, FCC, cUL *as per Manufacturer |
Physical
Wall Mounting |
100 x 100 mm |
Material of Construction |
Plastic |
Dimensions |
28.6 x 18.7 x 2.5" / 727.0 x 474.0 x 64.0 mm (with Stand) |
Weight |
11.22 lb / 5.09 kg |
Packaging Info
Package Weight |
14.99 lb |
Box Dimensions (LxWxH) |
31.5 x 19.9 x 5.6" |
