Product details
| Encoder Technology:
Optical
|
| Encoder Type:
Absolute
|
| Encoder Resolution:
-
|
| No. of Detents:
0 Detents
|
| Orientation:
Horizontal
|
| Push Switch:
Without Push Switch
|
| Encoder Output:
Binary Code
|
| Encoder Mounting:
Flange Mount
|
| Product Range:
AC58 Series
|
| Rotational Speed Max:
10000rpm
|
| No. of Channels:
-
|
| Shaft Type:
Solid Shaft
|
| Shaft Length:
19.5mm
|
| Shaft Diameter:
10mm
|
| Supply Voltage Min:
7VDC
|
| Supply Voltage Max:
30VDC
|
| Operating Temperature Min:
-40°C
|
| Operating Temperature Max:
85°C
|
| IP Rating:
IP64, IP65
|
| Termination:
M12 Connector
|
Other details
| Brand |
HENGSTLER |
| Part Number |
0574412 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
