- SMT RFI shield clip for EMI/RFI shields, midi
- Midi size (8.8mm long, 3.8mm high), for 0.17-0.30mm shield thickness
- Tin finish on contact area and termination
- Recommended for use with S01-30200500, S01-30300500 or S01-50250500 shield cans
- Top entry
- Operating temperature range from -40°C to +125°C
- Vertical connector orientation
- Beryllium copper base material of contact
- 8.79mm x 2.28mm x 3.55mm overall dimension (L x W x D)
Other details
| Brand |
HARWIN |
| Part Number |
S1711-46R |
| Quantity |
Each |
| Drawing EN |
 |
