Description
The M80-8890805 is a 8-contact 2mm female Datamate L-Tek DIL Cable Connector Kit with housing and contacts. Large bore is suitable for 22AWG cable (Ø1.1mm max insulation), M80-0110005 spare contacts. Housing is made of black UL94V-0 PBT with gold plated beryllium copper contact clip/brass shell contact base and gold plated termination. The M80 series socket has straight connector orientation and cable (crimp) connection type. It is suitable for Ø0.5mm mating pin size. The connector is intended for use as a low voltage connector in high packing density electronic equipment. The connector is polarised to prevent mismatching and can be produced with a latching feature jackscrew (L-Tek) format, with or without board mounting.
- 3A (at 25°C), 2.2A (at 85°C) Current rating
- 120VAC/DC Working voltage
- 20mR (initial), 25mR (after conditioning) Maximum contact resistance
- 1000MR (initial), 100MR (after conditioning) Minimum insulation resistance
- 500 operations Durability
Applications
Industrial
Product details
| No. of Contacts | 8Contacts |
| Contact Plating | Gold Plated Contacts |
| Gender | Receptacle |
| Product Range | Datamate L-Tek M80 Series |
| Contact Material | Brass |
| Contact Termination Type | Crimp |
| Pitch Spacing | 2mm |
| No. of Rows | 2Rows |
Other details
| Brand | HARWIN |
| Part Number | M80-8890805 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Drawing EN | |
| 3D Product Image EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 675.33 |
| 3-5 | ₹ 668.44 |
| 5-10 | ₹ 654.65 |
| 10+ | ₹ 640.87 |
Bulk discount will be automatically applied during checkout based on quantity.
