Description
The M50-9102042 is a 150mm 40-way IDC Ribbon Cable Assembly, female-to-female connectors, UL94V-0-rated black PBT housing, 100% tin-plated over nickel termination, gold-plated contact surface and phosphor bronze contact. IDC contact for high speed termination. Polarised to prevent mis-mating and secure cable retention with positive latching to header.
- 1.27mm (0.05") Contact pitch
- Angled connector orientation
- 0.5A Current rating
- 1R Maximum contact resistance
- 5MR Minimum insulation resistance
- 300VDC Minimum working voltage
- -40 to +105°C Operating temperature range
Applications
Commercial, Industrial
Product details
| Connector to Connector: IDC Receptacle to IDC Receptacle |
| No. of Positions: 40Ways |
| Cable Length - Imperial: 5.91" |
| Cable Length - Metric: 150mm |
| Connector Pitch: 1.27mm |
| Product Range: - |
Other details
| Brand | HARWIN |
| Part Number | M50-9102042 |
| Quantity | Each |
| Technical Data Sheet EN |  |
