Description
The M20-7871042 is a 20-contact 2.54mm female DIL Board-to-board Socket with gold plated phosphor bronze contacts, 100% tin over nickel plated termination and black UL94V-0 polyamide (nylon) 6T housing. The M20 series receptacle has vertical connector orientation, surface mount (SMT) connection type and dual entry style (bottom entry, top entry). It is suitable for use with 0.64mm square mating pin size. Suitable for interconnecting board to board. The socket is a box section design with a latch to locate and hold in an insulated housing.
- 3A Current rating
- 20mR Maximum contact resistance
- 1000MR Minimum insulation resistance
- 600VAC for one minute Voltage proof
- 2N Maximum insertion force
- 0.3N Maximum withdrawal force
Applications
Commercial, Industrial
Product details
| Connector Systems: Board-to-Board |
| Pitch Spacing: 2.54mm |
| No. of Rows: 2Rows |
| No. of Contacts: 20Contacts |
| Connector Mounting: Surface Mount |
| Product Range: M20 |
| Contact Material: Phosphor Bronze |
| Contact Plating: Gold Plated Contacts |
Other details
| Brand | HARWIN |
| Part Number | M20-7871042 |
| Quantity | Each |
| Technical Data Sheet EN |  |
