Description
The Gra-Vue Mini HD (3G)/SD-SDI to DVI Video Scaling Converter features real-time video/audio quality assurance watch dog function. It supports a variety of video input resolutions, including 525i, 625i, 720p, 1080i, and 1080p with automatic video input format detection. The watch dog function provides real-time video/audio survey and alarm.
The scaling converter also provides an aspect ratio marker, waveform analyzer, AFD, dynamic UMD, Tally, and an 8-channel audio VU meter. The built-in Web server allows easy remote control of the unit via a Web browser, and it fully supports the SNMP protocols for remote monitoring.
The MIO Viewer is used for setting up video/audio monitoring and display systems. It is suitable for many broadcasting and professional A/V monitoring applications such as control rooms, mobile trucks, production, post-production, and playout.
- Supports 525i, 625i, 720p, 1080i, 1080p input video formats with auto detection
- DVI/HDMI output resolutions up to 1920 x 1080p 1
Please Note:
HDMI output requires DVI to HDMI adapter (not included).
close
- Loopthrough SDI output
- Audio and video monitoring and alarm for signal loss, signal freeze, black field, and more
- Real-time video waveform analyzer
- Dynamic UMD and static programmable bi-color UMD
- Active Format Description (AFD)
- 8-channel audio VU meter display
- Selectable 4:3, 16:9, & full screen display
- Customized aspect ratio with 4:3 or 16:9 safe marker
- Built-in Web server allows easy remote control via a Web browser
- SMNP & Tally protocol support
- LED lights for input signal status and power status
- Quick key to change output display resolution
- Compact size
- Limited 1-Year Warranty
| Video Input | 1 x BNC, 75 ohms, HD (3G)/SD-SDI |
| Input Format | SDI: 480i, 576i, 720p, 1080i, 1080p |
| Video Output | 1 x DVI-I, female, supports HDMI protocol (separately available DVI to HDMI adapter required to connect to HDMI display) 1 x BNC, 75 ohms, SDI loopthrough |
| Output Resolution | 1024 x 768, 1280 x 720, 1280 x 1024, 1366 x 768, 1400 x 1050, 1600 x 900, 1680 x 1050, 1600 x 1200, 1920 x 1080 |
| Control | 1 x RJ-45 Ethernet for built-in Web server, TSL SMNP protocol RS-232 (via RJ-45 to DB15 adapter; not included) for TSL protocol, GPI for Tally and dynamic UMD |
| LED | Power status and input signal locking |
| Power | 12 VDC, 1 A |
| Working Temperature | 41 to 77�F (5 to 25�C) |
| Storage Temperature | 32 to 104�F (0 to 40�C) |
| Dimensions | 4.8 x 3.6 x 1.1" (12.3 x 9.2 x 2.9 cm) |
| Weight | 11.5 oz (326 g) |
| Packaging Info | |
|---|---|
| Package Weight | 1.45 lb |
| Box Dimensions (LxWxH) | 11.0 x 6.7 x 3.2" |
