Description
Product Overview
The MWDM2L-51PSB from Glenair is a Micro-D MWDM series solder cup metal shell connector with 51 contacts. Suitable for use with #26AWG wire.
- Aluminium alloy shell with nickel plating
- Liquid crystal polymer (LCP)/ polyphenylene sulphide(PPS) insulator
- Beryllium copper pin contacts with gold over nickel plating
- Blue colour fluorosilicone rubber interfacial seal
- Current rating is 3A, DWV is 600VAC sea level
- Minimum insulation resistance is 5000Mohm, maximum contact resistance is 8mohm
- Operating temperature range from -55°C to +150°C
- Through hole mounting hardware
Applications
Industrial
Product details
Other details
| Brand | GLENAIR |
| Part Number | MWDM2L-51PSB |
| Quantity | Each |
| Technical Data Sheet EN |  |
