Description
The FT232R is the latest device to be added to FTDI's range of USB UART interface Integrated Circuit Devices. The FT232R is a USB to serial UART interface with optional clock generator output, and the new FTDIChip-ID� security dongle feature. In addition, asynchronous and synchronous bit bang interface modes are available. USB to serial designs using the FT232R have been further simplified by fully integrating the external EEPROM, clock circuit and USB resistors onto the device.
- Single chip USB to asynchronous serial data transfer interface
- Entire USB protocol handled on the chip - No USB-specific firmware programming required
- UART interface support for 7 or 8 data bits, 1 or 2 stop bits & odd/even/mark/space/no parity
- Fully assisted hardware or X-On / X-Off software handshaking
- In-built support for event characters and line break condition
- New USB FTDIChip-ID� feature
- New configurable CBUS I/O pins
- Auto transmit buffer control for RS485 applications
- Transmit and receive LED drive signals
- New 48MHz, 24MHz,12MHz, and 6MHz clock output signal Options for driving external MCU or FPGA
Footnotes
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Product details
| Bridge Type: USB to UART |
| Supply Voltage Min: 1.8V |
| Supply Voltage Max: 5.25V |
| IC Case / Package: SSOP |
| No. of Pins: 28Pins |
| Operating Temperature Min: -40°C |
| Operating Temperature Max: 85°C |
| Product Range: FT232 |
| Qualification: - |
| MSL: MSL 3 - 168 hours |
Other details
| Brand | FTDI |
| Part Number | FT232RL-REEL |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
