- 78 series KNX switch mode power supply
- Input nominal voltage range from 110 to 240VAC/220VDC, 24V output
- 72mm wide, 35mm rail (EN 60715) mount, suitable for ETS 4 (or latest versions)
- Thermal protection, overload protection and short-circuit protection
- Two power supplies can be installed 15meters apart
- 50W output power, AC/DC input, DC output voltage conversion
- IP 20 protection, 1.45W stand-by power consumption
- Ambient temperature range from -5 to +45°C
- Output current is 640mA
- 3000VAC dielectric strength between input/output
Product details
Power Supply Applications:
ITE
|
No. of Outputs:
1 Output
|
Output Power Max:
50W
|
Output Voltage - Output 1:
12VDC
|
Output Current - Output 1:
4.2A
|
Output Voltage - Output 2:
-
|
Output Current - Output 2:
-
|
Output Voltage - Output 3:
-
|
Output Current - Output 3:
-
|
Output Voltage - Output 4:
-
|
Output Current - Output 4:
-
|
Input Voltage VAC:
110V AC to 240V AC
|
Power Supply Output Type:
Fixed
|
Product Range:
78 Series
|
Other details
Brand |
FINDER |
Part Number |
78.50.1.230.1202 |
Quantity |
Each |
Technical Data Sheet EN |
|
