| ₹ 6090.68 includes GST and import duties. | |
| B2B customers can avail ₹ 928.83 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The 20.23.9.024.4000 is a 2-pole Modular Step Relay with DC coil, 20.23 series. Double phase switch 1NO-1NC (SPST-NO+SPST-NC), test button with mechanical indicators. Possible to connect illuminated pushbuttons with the additional part 026.00. AgSnO2, cadmium-free contact. Module for illuminated pushbuttons. 35mm rail (EN 60715) mount.
- 4kV (1.2/50µs) Isolation, coil contacts
- 17.5mm Width
- Identification label
- IP20 Protection rating
Applications
Industrial, Power Management, Automation & Process Control
Product details
| Contact Material | Silver Tin Oxide |
| Relay Mounting | DIN Rail |
| Coil Type | - |
| Coil Resistance | 105ohm |
| Product Range | 20 Series |
| Relay Terminals | Screw |
| Contact Current | 16A |
| Approvals & Standards | - |
| Contact Voltage VAC | 250VAC |
| Coil Voltage | 24VDC |
| Contact Configuration | SPST-NO, SPST-NC |
| Contact Voltage VDC | - |
Other details
| Brand | FINDER |
| Part Number | 20.23.9.024.4000 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Manufacturer Catalogue EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 5968.87 |
| 3-5 | ₹ 5907.96 |
| 5-10 | ₹ 5786.15 |
| 10+ | ₹ 5664.33 |
Bulk discount will be automatically applied during checkout based on quantity.
