Description
Fender Quantum LT 16 Overview
Learn from Experts
From Manufacturer
Ideal for project studios, drum recording, ensembles, and electronic musicians, the Fender Quantum LT 16 is a 16x8 USB-C audio interface combining PreSonus conversion with two Fender-designed Hi-Z instrument inputs. With eight XLR-1/4" combo mic/line inputs on the front, DC-coupled outputs, and eight balanced line inputs, this interface can handle projects big and small.
The eight line inputs feature selectable +4 dBu or -10 dBV operation, ensuring they can support mic preamps, synths, mixers, and many other devices. With front-panel jacks, the Quantum LT 16 sports 14 line inputs total. The eight MAX-HD mic preamps provide up to 75 dB of transparent gain. The interface offers a balanced 1/4" TRS stereo pair for the main output and six DC-coupled 1/4" outputs for integrating modular and analog synthesizers. The 5-pin DIN MIDI I/O keeps you synchronized with legacy MIDI hardware. AD/DA up to 24-bit / 192 kHz ensures pristine audio quality. With features like loopback for podcasting, standalone Mixer mode for DAW-free mixing, and Mic Pre mode for using the interface as a pure eight-mic preamp, the Quantum LT 16 can bend to fit any application, private or professional. The Quantum LT 16 includes a free perpetual license for Fender Studio Pro.
- Fender Quantum LT 16 16x8 USB-C Audio Interface
- Limited 2-Year Manufacturer Warranty
No additional resources available
Fender Quantum LT 16 Specs
| Channels of I/O |
16 Inputs / 8 Outputs
|
| Maximum Sampling Rate |
192 kHz / 24-Bit
|
| Number of Microphone Inputs |
6
|
| Analog Audio I/O |
6x Combo XLR-1/4" TRS Mic/Line Input
2x Combo XLR-1/4" TS Mic/Line/Hi-Z Input 8x 1/4" TRS Line Input 6x 1/4" TRS Line Output 2x 1/4" TRS Line Output 1x 1/4" TRS Headphone Output |
| Digital Audio I/O |
No
|
| Host Connection |
USB-C
|
| Power Requirements |
USB Bus Power
|
| Display |
No
|
| Channels of I/O |
16 Inputs / 8 Outputs
|
| Maximum Sampling Rate |
192 kHz / 24-Bit
|
| Number of Microphone Inputs |
6
|
| Built-In Microphone |
No
|
| Input Level Adjustment |
8x Knob
|
| Pad |
No
|
| Gain/Trim Range |
75 dB
|
| High-Pass Filter |
No
|
| Solo/Mute |
No
|
| Analog Audio I/O |
6x Combo XLR-1/4" TRS Balanced Mic/Line Input (Front Panel)
2x Combo XLR-1/4" TS Mic/Line/Hi-Z Input (Front Panel) 8x 1/4" TRS Balanced Line Input 6x 1/4" TRS Line Output 2x 1/4" TRS Balanced Line Output 1x 1/4" TRS Headphone Output |
| Phantom Power |
48 V
|
| Digital Audio I/O |
No
|
| Host Connection / USB |
USB-C
|
| USB (Non-Host) |
No
|
| Sync I/O |
No
|
| Network I/O |
No
|
| MIDI I/O |
1x DIN 5-Pin Input
1x DIN 5-Pin Output |
| Expansion Slots |
No
|
| Wireless |
No
|
| Sample Rates |
Up to 192 kHz
|
| Sample Rate Conversion |
No
|
| Bit Depths |
24-Bit
|
| Sync Sources |
No
|
| Media/Memory Card Slot |
No
|
| OS Compatibility |
Windows / macOS
|
| Required Hardware |
USB Cable
|
| Power Requirements |
USB Bus Power
|
| Dimensions |
19 x 5 x 1.75" / 48.3 x 12.7 x 4.45 cm
|
| Weight |
4.8 lb / 2.2 kg
|
| Package Weight |
8.11 lb
|
| Box Dimensions (LxWxH) |
23.9 x 10 x 5.3"
|
All product and company names are trademarks or registered trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
