Description
ETC Response Mk2 Overview
The portable ETC Response Mk2 Two-Port DMX/RDM Output Gateway, in white, provides data distribution using ETC's network technology. Designed for the Net3 protocol using industry-standard sACN, DMX, and RDM, the Gateway is offered as a solution that unlocks the power of your networked system.
Key Features
- Distributes DMX and RDM data over Ethernet
- Supports Net3 protocol powered by ACN
- Onboard screen and controls for status and configuration
- Power and network status indicators
- Touch to Wake sensor
- Power over Ethernet (PoE) or external DC power supply
- Configurable using Concert Software
Items Included
- ETC Response Mk2 Two-Port DMX/RDM Output Gateway (Portable, White)
Additional Resources
No additional resources available
ETC Response Mk2 Specs
Key Specs
| Inputs/Outputs |
2x XLR 5-Pin (DMX) Output
|
| Channels |
1024 (DMX)
|
| Power Source |
AC Adapter
|
| Protocol |
DMX512, RDM, sACN
|
General
| Inputs/Outputs |
2x XLR 5-Pin (DMX) Output
|
| Channels |
1024 (DMX)
|
| Dimming |
Optional
|
| Cooling System |
No
|
Power
| Power Source |
AC Adapter
|
| Power Consumption |
4 W
|
| Input Power |
12 to 24 VDC
|
| PoE Port Power |
Yes
|
Compatibility
| Protocol |
DMX512, RDM, sACN
|
| Operating Conditions |
32 to 104°F / 0 to 40°C at 5 to 95% Humidity
|
| Storage Conditions |
-40 to 158°F / -40 to 70°C
|
| Certifications |
cETLus, CE, RoHS, WEEE
|
| Environmental Resistance |
No
|
| Dimensions |
6.4 x 4.5 x 4.3" / 16.3 x 11.4 x 10.9 cm
|
| Weight |
3.47 lb / 1.57 kg
|
