Description
ETC Port Replicator Overview
This HPU Port Replicator for Hog Consoles from ETC is a hybrid processor unit that can act either as a rack-mounted console or as a DMX Processor connected to another Hog family console. Capable of 64 universes of output from a single 2U 19" rack mount device, this unit is designed for applications where permanent front-panel interfaces are not necessary, such as cruise ships, theme parks, and architectural lighting installations.
Features
Robust Hog OS operating system
Built-in 8" full color multitouch display
Supports two external DisplayPort monitors/touchscreens
32,768 output channels, expandable with additional HPU units
8 Neutrik XLR-5 DMX outputs
sACN and Art-Net
Dual RJ45 Ethernet connections for HogNet and FixtureNet
Optional port replicator to bring all connections to the front of the equipment rack
- ETC HPU Port Replicator for Hog Consoles
- Keyboard
- Mouse
- Limited 2-Year Manufacturer Warranty
No additional resources available
ETC Port Replicator Specs
Key Specs
| Inputs/Outputs |
5x USB-A Female
2x USB-C Female 8x XLR 5-Pin (DMX) Female Output 1x RJ45 (Gigabit Ethernet) Female Input 1x RJ45 (Gigabit Ethernet) Female Output 2x DisplayPort Female Output 3x Input 1x IEC Power Input 2x Phoenix (RGB) |
| Channels |
32,768 (DMX)
|
| Power Source |
AC Power
|
| Protocol |
ArtNet, DMX512, sACN
|
General
| Inputs/Outputs |
5x USB-A Female
2x USB-C Female 8x XLR 5-Pin (DMX) Female Output 1x RJ45 (Gigabit Ethernet) Female Input 1x RJ45 (Gigabit Ethernet) Female Output 2x DisplayPort Female Output 3x Input 1x IEC Power Input 2x Phoenix (RGB) |
| Channels |
32,768 (DMX)
|
| Dimming |
Yes
|
| Cooling System |
Active
|
Power
| Power Source |
AC Power
|
| Power Consumption |
120 W
|
| Input Power |
100 to 250 VAC, 50 / 60 Hz
|
| Fuse |
5 A / Slow-Blow
|
Compatibility
| Protocol |
ArtNet, DMX512, sACN
|
Physical
| Environmental Resistance |
No
|
| Rack Mount |
2 U
|
| Dimensions |
19.1 x 14.0 x 3.5" / 48.5 x 35.6 x 8.9 cm
|
| Weight |
15 lb / 6.8 kg
|
