Description
The ESP32-C6 has integrated 2.4 GHz Wi-Fi 6 (802.11ax) radio, and also supports the 802.11b/g/n standard for backward compatibility.
Features & Specs
- MCU
- ESP32-C6 embedded, 32bit RISC-V Single Core microprocessor, up to 160MHz
- 320KB ROM
- 512KB HP SRAM
-
16KB LP SRAM
-
Wi-Fi
- 1T1R in 2.4 GHz band
- Operating frequency: 2412 ~ 2484 MHz
- IEEE 802.11ax-compliant
-
Fully compatible with IEEE 802.11b/g/n protocol
-
Bluetooth
- Bluetooth LE: Bluetooth 5.3 certified
- Bluetooth mesh
- High power mode (20 dBm)
- Speed: 125 Kbps, 500 Kbps, 1 Mbps, 2 Mbps
- Advertising extensions
- Multiple advertisement sets
- Channel selection algorithm #2
- LE power control
-
Internal co-existence mechanism between Wi-Fi and Bluetooth to share the same antenna
-
IEEE 802.15.4
- Compliant with IEEE 802.15.4-2015 protocol
- OQPSK PHY in 2.4 GHz band
- Data rate: 250 Kbps
- Thread 1.3
-
Zigbee 3.0
-
Hardware
- Interfaces: GPIO, SPI, parallel IO interface, UART, I2C, I2S, RMT (TX/RX), pulse counter, LED PWM, USB Serial/JTAG controller, MCPWM, SDIO2.0 slave controller, GDMA, TWAI® controller, on-chip debug functionality via JTAG, event task matrix, ADC, temperature sensor, system timer, general-purpose timers, and watchdog timers
- 40 MHz crystal oscillator
- SPI flash
-
On-board PCB antenna
-
RoHS/REACH certified
-
FCC/CE-RED/SRRC Certified (RF)
Features & Specs
- MCU
- ESP32-C6 embedded, 32bit RISC-V Single Core microprocessor, up to 160MHz
- 320KB ROM
- 512KB HP SRAM
-
16KB LP SRAM
-
Wi-Fi
- 1T1R in 2.4 GHz band
- Operating frequency: 2412 ~ 2484 MHz
- IEEE 802.11ax-compliant
-
Fully compatible with IEEE 802.11b/g/n protocol
-
Bluetooth
- Bluetooth LE: Bluetooth 5.3 certified
- Bluetooth mesh
- High power mode (20 dBm)
- Speed: 125 Kbps, 500 Kbps, 1 Mbps, 2 Mbps
- Advertising extensions
- Multiple advertisement sets
- Channel selection algorithm #2
- LE power control
-
Internal co-existence mechanism between Wi-Fi and Bluetooth to share the same antenna
-
IEEE 802.15.4
- Compliant with IEEE 802.15.4-2015 protocol
- OQPSK PHY in 2.4 GHz band
- Data rate: 250 Kbps
- Thread 1.3
-
Zigbee 3.0
-
Hardware
- Interfaces: GPIO, SPI, parallel IO interface, UART, I2C, I2S, RMT (TX/RX), pulse counter, LED PWM, USB Serial/JTAG controller, MCPWM, SDIO2.0 slave controller, GDMA, TWAI® controller, on-chip debug functionality via JTAG, event task matrix, ADC, temperature sensor, system timer, general-purpose timers, and watchdog timers
- 40 MHz crystal oscillator
- SPI flash
-
On-board PCB antenna
-
RoHS/REACH certified
-
FCC/CE-RED/SRRC Certified (RF)
