ESI aktiv 05 Overview
The single aktiv 05 from ESI is a high-quality 2-way powered monitor developed for audio engineers and producers looking for high-performance sound reproduction at an affordable price. The monitor utilizes a 1" silk dome tweeter and a 5" Kevlar curved-cone woofer, which combine to provide a flat frequency response of 50 Hz to 20 kHz with an SPL output of 88 dB (±3dB). Designed for use with balanced and unbalanced signals, the monitor offers a combo XLR-1/4" input connector. The built-in amplifier provides 30W to the tweeter and 30W to the woofer, while the universal power supply includes a switch for 115V/230V operation, allowing the speaker to be used anywhere in the world. The aktiv 05 ships with a standard IEC power cord.
- 2-way powered speaker / active studio monitor speaker
- LF Driver: 5" Kevlar curved cone (magnetic shielding type)
- HF Driver: 1" silk dome tweeter
- Output Power: 60W (HF 30W, LF 30W)
- Magnetically shielded for desktop operation
- Balanced / Unbalanced Connectors: combo XLR-1/4"
- Frequency Response: 50 Hz - 20 kHz
- Crossover Frequency: 2.5 kHz
- SPL: 88 dB ±3 dB
- Operating Voltage: 100-240 VAC, 50/60 Hz, with 115/230 VAC selection switch
- Indicator: blue power LED on the front
- Standby Function, can be turned on and off
In the Box
- ESI aktiv 05 - 5" Studio Reference Monitor (Single)
- Power Cord
- Limited 1-Year Manufacturer Warranty
ESI aktiv 05 Specs
| Monitor Type & Configuration |
Active 2-Way |
| Number of Included Monitors |
Single Monitor |
| Enclosure |
Bass-Reflex/Ported, Shielded |
| Total Power Output |
60 W |
Drivers
| Tweeter |
1 x 1" / 25.4 mm Silk Dome |
| Woofer |
1 x 5" / 12.7 cm Kevlar Cone
|
| Amplifiers |
HF: 30 W
LF: 30 W |
Performance
| Frequency Range |
50 Hz to 20 kHz |
| Maximum Sound Pressure Level (SPL) |
88 dB |
| Total Harmonic Distortion (THD) |
1% |
| Analog Input Sensitivity/Gain |
-5.4 dBu (Continuously Variable) |
Signal Processing
| Crossover Frequency |
2.5 kHz |
Connectivity
| Audio I/O |
1 x Combo XLR-1/4" TRS Balanced/Unbalanced Input (23.3 Kilohms) |
| Network I/O |
None |
| USB |
None |
| Wireless |
None |
Power
| AC Input Power |
100 to 240 VAC, 50/60 Hz
|
| Power Consumption |
85 W |
Physical
| Color |
Black |
| Dimensions (W x H x D) |
6.9 x 9.8 x 7.9" / 176 x 250 x 200 mm |
| Weight |
9.9 lb / 4.5 kg |
Packaging Info
| Package Weight |
10.495 lb |
| Box Dimensions (LxWxH) |
13.2 x 10.2 x 9.8" |
