Description
Erica Synths XenoDrive Overview
Unleash and shape unique sound textures live or in the studio with the Erica Synths Xenodrive, a stereo distortion, overdrive, and waveshaper FX unit, which combines several audio processing modules into a single machine. Capable of generating everything from simple harmonic enhancement to utter sonic destruction, this FX processor takes you into unexplored sonic territory.
The processing path begins with an input gain stage with up to 24 dB of gain. Next, it's passed through an adjustable compressor and a germanium overdrive circuit with adjustable drive and tone. The X MOD segment is an envelope follower which can apply a positive or inverted envelope. Next, you can further mangle your sounds with a waveshaper that provides the ability to shift the phase of the wave, to control it on an XY axis, and to add gain and wave folding. Finally, your signal is passed through a 2-band shelving EQ and a noise gate. The Xenodrive features balanced 1/4" stereo pair inputs and outputs, a footswitch input for hands-free control, and fully functional 5-pin DIN MIDI I/O. The Xenodrive includes a 12 VDC power supply.
The audio signal is processed by a germanium diode overdrive emulation with drive and tone controls. It then enters the wavetable-based waveshaper (16x16 carefully selected waves) that alters the incoming audio signal by wrapping it into the selected wave and, depending on the shaper gain setting, folds it. The envelope follower controls the wave selection on the X-axis of the wavetable. The signal then passes through the EQ and noise gate, and finally into the balanced output stage.
- Stereo pair of 1/4" TRS balanced inputs and outputs
- 5-pin DIN MIDI I/O
- USB-B for preset upload/backup
- 1/4" TS footswitch input for bypass, freeze, or navigation
- Erica Synths Xenodrive Stereo Distortion/Overdrive FX Processor
- Power Supply
- Limited 2-Year Manufacturer Warranty
No additional resources available
Erica Synths XenoDrive Specs
| Panel Type |
OLED
|
| Touchscreen |
No
|
| USB I/O |
1 x USB-B Female Input/Output
|
| Audio I/O |
2x 1/4" TRS Line Input
1x DIN 5-Pin MIDI Input 1x 1/4" TS Input (Footswitch) 2x 1/4" TRS Line Output 1x DIN 5-Pin MIDI Output |
| Power Source |
AC Adapter with Power Brick (Included)
|
| DC Input Power |
12 VDC
|
| Color |
Black
|
| Material of Construction |
Aluminum
|
| Package Weight |
2.875 lb
|
| Box Dimensions (LxWxH) |
14.2 x 6.7 x 4.3"
|
