| ₹ 4041.48 includes GST and import duties. | |
| B2B customers can avail ₹ 616.33 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The Q33310F700017 SG-310SCF 20 MHZ C is a 3.2 x 2.5 x 1.05mm 3.3V Crystal Oscillator with standby (ST) function. The SPXO standard SG-310SCF series oscillator with no load condition and to maintain stable operation, provide a by-pass capacitor at a location as near as possible to the power source terminal of the crystal product.
- 2.5mA Maximum current consumption
- 45 to 55% Symmetry
- 15pF Maximum output load
- 4ns Maximum output rise and fall time
- 10s Maximum oscillation start-up time
Clock & Timing
Other details
| Brand | EPSON |
| Part Number | Q33310F700017 |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| EOL Notices EN | |
| Product Change Notice EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 3960.65 |
| 3-5 | ₹ 3920.24 |
| 5-10 | ₹ 3839.41 |
| 10+ | ₹ 3758.58 |
Bulk discount will be automatically applied during checkout based on quantity.
