EnGenius DuraFon UHF Overview
-
1Description
-
2Key Features
-
3DuraFon exclusive private intercom
-
4DuraFon exclusive group broadcast
-
52-way radio UHF broadcast
-
6Minimizes equipment needs, saves money
-
7Operates independently of Wi-Fi networks
-
8Durable, ruggedized design
-
9Superior long-range performance
-
10Highly secure
The dual-mode radio phone, DuraFon-UHF-HC handset is the extremely durable, long-range cordless phone with a UHF 2-way radio that allows communication with both UHF 2-way radios and phone users. It's ideal for employees that need to make and receive calls and want the added convenience of communicating with other personnel using UHF 2-way radios in the area.
- On-premises mobility for managers and staff
- Single handset for communication flexibility
- Easy integration and deployment
- Durable and reliable handset
DuraFon exclusive private intercom
The DuraFon-UHF-HC handset provides private handset-to-handset communications independent of the Base Unit to another specific DuraFon handset.
DuraFon exclusive group broadcast
DuraFon-UHF-HC handsets have the ability to broadcast to other DuraFon handsets that have joined a communication group.
2-way radio UHF broadcast
DuraFon-UHF-HC handset offers "Push-to-Talk" through the handset's Broadcast button, allowing users to instantly broadcast to various handset users.
Minimizes equipment needs, saves money
Designed to simplify deployment, the DuraFon-UHF-HC features single cell technology that leverages a single 900 MHz base station for long-range coverage, eliminating the need for added base stations or repeaters, helping companies lower their capital expenses through faster deployment.
Operates independently of Wi-Fi networks
DuraFon-UHF-HC avoids adding traffic over Wi-Fi networks, which means there's no need to worry about roaming or QoS issues that are typical with voice communications on a WLAN.
Durable, ruggedized design
The DuraFon-UHF-HC durable, rugged handset is designed for use in harsh environments and is IP55-rated for protection against dust and water. Able to withstand 6-foot drops over 50 consecutive times onto concrete floors, the proven durability of EnGenius DuraFon handsets ensure the phones will survive in the most challenging environments even when subjected to drops and shocks.
Superior long-range performance
DuraFon-UHF-HC implements a high-powered 900 MHz proprietary air protocol, with high RF transmission and sensitivity to provide superior range and coverage for the industrial market; covering up to 250,000 sq. ft. indoors.
Adopting 900 MHz (902~928 MHz) FHSS (Frequency Hopping Spread Spectrum) technology, the DuraFon-UHF-HC ensures a high level of privacy during conversations.
UPC: 655216008106
Table of Contents
- Description
- Key Features
- DuraFon exclusive private intercom
- DuraFon exclusive group broadcast
- 2-way radio UHF broadcast
- Minimizes equipment needs, saves money
- Operates independently of Wi-Fi networks
- Durable, ruggedized design
- Superior long-range performance
- Highly secure
EnGenius DuraFon UHF Specs
General
| Product Type |
Two-way radio |
| Two-Way Radio Form Factor |
Portable |
| Width |
2.4 in |
| Depth |
1.5 in |
| Height |
5.6 in |
| Weight |
9.06 oz |
Radio System
| Type |
UHF |
| Channels |
5-channel |
| Vibrating Alert |
Yes |
| Controls |
Power/volume knob, mode button, push-to-talk (PTT) button, full keypad |
| Display Information |
Caller ID |
Radio System Features
| Audible Call Alert |
Yes |
| Keypad Lock |
Yes |
| Built-in Speaker |
Yes |
| Additional Functions |
Intercom |
Display
| Type |
LCD display - monochrome |
Miscellaneous
| Antenna |
External |
| Connections |
Headset jack - sub-mini-phone 2.5 mm |
| Compliant Standards |
IP55 |
| Included Accessories |
Charging stand, power adapter |
Environmental Parameters
| Min Operating Temperature |
14 °F |
| Max Operating Temperature |
140 °F |
| Min Storage Temperature |
14 °F |
| Max Storage Temperature |
158 °F |
| Humidity Range Operating |
20 - 75% |
Battery
| Technology |
Rechargeable - lithium ion |
| Capacity |
2300 mAh |
| Run Time (Up To) |
6 hour(s) |
| Recharge Time |
4 hour(s) |
Manufacturer Warranty
| Service & Support |
Limited warranty - 1 year |
Packaging Info
| Package Weight |
1.69 lb |
| Box Dimensions (LxWxH) |
11.4 x 7.7 x 2.8" |
