Product details
Encoder Technology:
Mechanical
|
Encoder Type:
Incremental
|
Encoder Resolution:
24CPR
|
No. of Detents:
-
|
Orientation:
Vertical
|
Push Switch:
With Push Switch
|
Encoder Output:
Parallel, UART
|
Encoder Mounting:
Panel Mount
|
Product Range:
X4 Series
|
Rotational Speed Max:
120rpm
|
No. of Channels:
2Channels
|
Shaft Type:
Round End
|
Shaft Length:
14.1mm
|
Shaft Diameter:
6mm
|
Supply Voltage Min:
3.2VDC
|
Supply Voltage Max:
5.5VDC
|
Operating Temperature Min:
-30°C
|
Operating Temperature Max:
85°C
|
IP Rating:
IP68
|
Termination:
Socket Connector
|
Other details
Brand |
ELMA |
Part Number |
X4-P2B00-4S1 |
Quantity |
Each |
Technical Data Sheet EN |
 |
