Description
The 614NGN from EBM Papst is DC Tubeaxial fan. This fan is designed using fibreglass reinforced PBT plastic housing material with 60mm x 60mm x 25mm size.
- Air flow is 24.7CFM
- Noise rating is 35dBA
- Supply voltage is 12VDC
- Sintec sleeve bearing
- Air exhaust over struts. Rotational direction CCW looking at rotor
- Electronic commutation completely integrated
- Protected against reverse polarity, blocking, overloading
- UL, CSA and VDE approved
Applications
Industrial
Product details
| Supply Voltage | 24V |
| Power Connection Type | 2 Lead Wires |
| Flow Rate - Metric | 0.69m³/min |
| Fan Frame Size | 60mm |
| Current Type | DC |
| Product Range | 600NG Series |
| Flow Rate - Imperial | 24.7cu.ft/min |
| Current Rating | - |
| Noise Rating | 35dBA |
| Bearing Type | Sleeve |
| External Depth | 25mm |
Other details
| Brand | EBM-PAPST |
| Part Number | 614NGN |
| Quantity | Each |
| Technical Data Sheet EN |  |
