Description
Product Overview
628-22-GH-P1-E7-S1 is a series 628 industrial pressure transmitter ideal for OEMs with 1% full-scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the series 628 transmitter to measure the pressure in a multitude of processes from hydraulic oils to chemicals. Typical applications include compressors, pumping systems, irrigation equipment, hydraulic and industrial process monitoring.
- Robust 316L SS oil filled sensor provides shock and vibration resistance
- Pressure range from 0 to 600psi
- General purpose housing
- 1/4" male NPT process connection
- Hirschmann DIN plug w/6ft cable connection
- 4-20mA signal output
- Temperature limit range from 0 to 200°F (-18 to 93°C)
- Response time of 300ms and mount in any position
- NEMA 4X rated enclosure provides protection in harsh environments
- Meet pressure measurement specifications from low to very high
Product details
Other details
| Brand | DWYER |
| Part Number | 628-22-GH-P1-E7-S1 |
| Quantity | Each |
| Technical Data Sheet EN |  |
