Description
Product Overview
DG57CM-5021-76-1012-R is a DG57CM series automotive / electric vehicle relay. It is a general purpose automotive or industrial relay optimised for switching DC voltages upto 145VDC and 80A in a miniature package.
- AgSnO? contact material, SPST-NO (1N/O, 1Form A) contact arrangement
- In cover, dust cover - IP54 environmental protection, flat blades connection method
- Integral resistor, 12VDC nominal voltage
- 90 ohm coil resistance at (±10%, 23°C)
- 7.2VDC max must operate voltage at (23°C), 17.4VDC max allowable voltage at (23°C)
- 1.2VDC max must release voltage, 145VDC max switching voltage
- 80A at 12VDC, 60A at 36VDC, 50A at 48VDC, 30A at 72VDC, 5A at 145VDC rated load
- 150A at 12.8VDC (3secs) max switching current
- Operating time is 7ms typ, release time is 2ms typ
- Ambient temperature range from -40°C to 125°C, dimension is 39.1 x 28 x 26mm (L x W x H)
Product details
Other details
| Brand | DURAKOOL |
| Part Number | DG57CM-5021-76-1012-R |
| Quantity | Each |
| Technical Data Sheet EN |  |
