Description
Dreadbox Euphoria Overview
Modular synthesizer enthusiasts in search of a vintage-style phaser will be impressed with the 10 HP Dreadbox Chromatic Euphoria, a fully analog 8-stage phase shifter with a warm vintage sound based on OTA chips. The module is capable of creating phase AM sounds and can be used with lower signal level inputs such as fretted instruments.
The internal voltage controlled LFO features a triangle shape and a wide frequency range (1 min to audio range). Euphoria sports manual and CV control over feedback, +/- manual, and LFO rate inputs as well as CV control over the LFO output level. An Eurorack ribbon cable is included.
- Full analog 8-stage phase shifter
- Warm vintage sound based on OTA chips
- Can create phase AM sounds
- Can be used with lower level signal inputs (i.e. fretted instruments)
- Internal voltage controlled LFO with a triangle shape and a wide frequency range (about 1 min into the audio range)
- Current consumption: 58mA @ +12V , 52mA @ -12V
- 35mm depth
In the Box
- Dreadbox Chromatic Euphoria / 8-Stage Phaser (10 HP)
- Ribbon Cable
- Limited 1-Year Manufacturer Warranty
Dreadbox Euphoria Specs
Key Specs
| Sound Generation |
Analog
|
| Maximum Polyphony |
Not Specified by Manufacturer
|
| Audio I/O |
2 x 1/8" / 3.5 mm TS Unbalanced Mono Line/Instrument Input (Eurorack Compatible)
2 x 1/8" / 3.5 mm TS Unbalanced Mono Main Output (Eurorack Compatible) |
| MIDI I/O |
No
|
| CV/Gate I/O |
3 x 1/8" / 3.5 mm TS CV Input
1 x 1/8" / 3.5 mm TS CV Output |
| Patch Points |
8 x 1/8" / 3.5 mm TS
|
| Eurorack Current Consumption |
58 mA on +12 V Rail
52 mA on -12 V Rail |
| Horizontal Pitch |
10 HP
|
General
| Item Type |
Eurorack Module
|
| Sound Generation |
Analog
|
| Keyboard |
No
|
| Expression Controls |
No
|
| Number of Pads |
No
|
| Display |
No
|
Sounds
| Maximum Polyphony |
Not Specified by Manufacturer
|
| Built-In Effects |
Yes
|
| Built-In Speaker |
No
|
Synthesis
| Oscillators |
No
|
| Mixer |
No
|
| Amplifiers |
No
|
| Envelopes |
No
|
| Filters |
No
|
| LFOs |
Number of LFOs: 1 x Global
Waveforms: Triangle |
Sequencing & Recording
| Sequencer |
No
|
| Arpeggiator |
No
|
Connectivity
| Audio I/O |
2 x 1/8" / 3.5 mm TS Unbalanced Mono Line/Instrument Input (Eurorack Compatible)
2 x 1/8" / 3.5 mm TS Unbalanced Mono Main Output (Eurorack Compatible) |
| Pedal Support |
No
|
| MIDI I/O |
No
|
| CV/Gate I/O |
3 x 1/8" / 3.5 mm TS CV Input
1 x 1/8" / 3.5 mm TS CV Output |
| Patch Points |
8 x 1/8" / 3.5 mm TS
|
| Sync I/O |
No
|
| Network I/O |
No
|
| USB |
No
|
| Media/Memory Card Slot |
No
|
| Bluetooth |
No
|
Compatibility
| Included Software |
No
|
| Mobile App Compatible |
No
*As of January, 2023: Check with manufacturer for the most up-to-date compatibility |
Power
| Power Requirements |
Eurorack Power
|
| Eurorack Current Consumption |
58 mA on +12 V Rail
52 mA on -12 V Rail |
Physical
| Color |
Orange
|
| Horizontal Pitch |
10 HP
|
| Included Accessories |
No
|
