Description
Drawmer 1974 Overview
- 1Description
- 2Genuine Stereo Operation with Accurate Potentiometers
- 3Fully Parametric with Variable Q
- 4Variable Low- and High-Cut Filters
- 5Switchable Slope Settings
Produce immersive mixes in vintage style with the 1974 from Drawmer, a genuine stereo, four-band, parametric equalizer rack unit packed with all the features you need to sculpt truly professional sounding tracks. Ideal for mixing or mastering applications, the 1974 delivers a delicate touch with easy recall and excels at tuning out undesirable signals at extreme frequencies, adding analog warmth to recordings in a way that is difficult to emulate digitally.
This 19", 1 RU EQ processor sports stepped, indented pot controls for surgical precision and a wide range of vital features for sound sculpting, including variable high- and low-pass filters, adjustable slope selection with peak settings on high- and low-band filters, and highly versatile variable Q selection, which allows you to widen or narrow your boosting or cutting of frequencies for subtle fine tuning or addressing particularly problematic recordings. True hardware bypass makes it easy to perform A/B comparisons, so you can be sure you find the optimal settings without too much fiddling. The internal toroidal, linear power supply delivers extremely low-noise performance and features switchable voltages for global compatibility, and the unit includes an AC power cord to get you mixing right away.
This is especially useful when bracketing individual tracks where it will be necessary to cut the bass to remove rumble or cut the top to remove hiss, as these undesirable signals will just add up as the tracks are layered. For instance, cut every instrument below 100 Hz except those within that spectrum, such as the kick, bass, or synths to provide extra headroom to work, and also tighten up the bass making it sound less muddy.
The Peak setting is quite a unique feature in that it adds a narrow bell shape to the 12 dB per octave low-band filter at the knee frequency just before it rolls off. Especially useful on kick drums, it magnifies and gives extra weight to the hit while still filtering out any subsonic junk without muddying the lower mid. It'll give your kick an added sense of power and precision.
In the Box
- Drawmer 1974 Four-Band Stereo Parametric Equalizer
- AC Power Cord
- Limited 1-Year Manufacturer Warranty
- Description
- Genuine Stereo Operation with Accurate Potentiometers
- Fully Parametric with Variable Q
- Variable Low- and High-Cut Filters
- Switchable Slope Settings
Drawmer 1974 Specs
| Frequency Response |
20 Hz to 20 kHz (±0.2 dB)
|
| Input Impedance |
?20 Kilohms
|
| Output Impedance |
<100 Ohms
|
| Maximum Input Level |
+26 dBu
|
| Maximum Output Level |
+26 dBu (Into 10 Kilohm Load)
|
| Crosstalk |
<-75 dB (at 1 kHz)
|
| THD + N |
0.007% (at 1 kHz)
|
| Audio I/O |
2x XLR 3-Pin Line Input (1 Stereo Pair)
2x XLR 3-Pin Line Output (1 Stereo Pair) |
| Power Source |
AC Input (Built-In)
|
| Power Consumption |
15 VA
|
| AC Input Power |
115 / 230 VAC, 50/60 Hz (User Selected)
|
| Mounting |
Front: 4 x Standard Rackmount Hole
|
| Color |
Black
|
| Material of Construction |
Steel, Aluminum
|
| Dimensions |
19 x 8 x 1.7" / 48.2 x 20.2 x 4.4 cm
|
| Weight |
6.2 lb / 2.8 kg
|
| Package Weight |
6.96 lb
|
| Box Dimensions (LxWxH) |
22.2 x 14.9 x 4.6"
|
