Description
DITEK DTK-2LVLPLV Overview
Designed for up to 2-pair connections, the DITEK DTK-2LVLPLV Low-Voltage Surge Protector guards a variety of applications using AC and DC circuits. This compact DIN rail mountable device features terminals that support 30 to 12 AWG hardwire connections. It features a 24V service voltage and a 39V clamping voltage, supporting a max surge current of 5000A with a 5A continuous current rating.
UPC: 782980500854
In the Box
- DITEK DTK-2LVLPLV Low-Voltage Surge Protector
- DIN Rail Mounting Kit
- Limited 10-Year Manufacturer Warranty
Additional Resources
DITEK DTK-2LVLPLVSpecs
Inputs / Outputs
| Connector |
30 to 12 AWG Hardware Terminal
|
| Connection |
2 Pair
|
| Voltage |
24 V (Service) 39 V (Clamping)
|
| Current |
5000 A Surge Current
5 A Max Continuous Current |
Power
| Power Source |
AC Input
|
Environmental
| Operating Temperature |
-40 to 158°F / -40 to 70°C
|
| Operating Humidity |
95%
|
Physical
| Mounting |
1x DIN Rail
|
| Color |
Black
|
| Dimensions |
3.3 x 1.5 x 1.1" / 83 x 39 x 28 mm
|
| Weight |
2.4 oz / 68 g
|
Packaging Info
| Package Weight |
0.16 lb
|
| Box Dimensions (LxWxH) |
5 x 4 x 1.5"
|
