Description
CZI IR10 Infrared Laser Zoom Searchlight Overview
Conduct stealth surveillance and inspection missions using the IR10 Infrared Zoom Spotlight for DJI Matrice 200 V2/Matrice 300 Series from CZI. This invisible fill-in light features a 12W 940nm wavelength laser, which works with the drone's H20N/H20T gimbal's IR mode. The infrared light can generate an actionable image from a distance of up to 0.62 miles away using a 70x optical zoom. To ensure the light operates safely, internal protection circuitry is used to monitor the power supply and temperature. You also get selectable overdischarge and overvoltage protection.
Additional Features
- Pitch and yaw adjustments
- Brightness adjustment
- 0.56 to 45° FOV
- DJI SkyPort 2.0 connection
Items Included
- CZI IR10 Infrared Zoom Spotlight for DJI Matrice 200 V2/300 Series
- Limited 1-Year Manufacturer Warranty
Additional Resources
No additional resources available
CZI IR10 Infrared Laser Zoom Searchlight Specs
General
| Compatibility |
DJI Matrice 200 V2 / Matrice 300 RTK / Matrice 350 RTK / H20N / H20T
|
| Zoom |
70x
|
| Gimbal |
IR10 Mount (Pitch): -125 to +40°
No. 1 Head Port with H20T (Yaw): -25 to +45° No. 2 Head Port with H20T (Yaw): -15 to +12° No. 1 Head Port with H20 (Yaw): +/- 45° No. 2 Head Port with H20 (Yaw): +/- 45° |
| IR Illumination |
Power: 12 W
Wavelength: 940 nm Effective Distance: >/= 0.62 Miles / 1000 m Laser Safety Distance: >/= 295 Feet / 90 m Field of View: 0.56 to 45° |
Inputs/Outputs
| Interface |
DJI SkyPort 2.0
|
Power
| Power Source |
Proprietary Interface
|
| Power Consumption |
40 W
|
| Power |
Out Light Power: 12 W +/- 0.5 W
|
Physical
| Color |
Black
|
| Certifications |
CE, FCC, RoHS
|
| Operating Conditions |
-4 to 122°F / -20 to 50°C
|
| Dimensions |
7.3 x 6.2 x 5" / 186 x 158 x 128 mm
|
| Weight |
1.8 lb / 800 g
|
