Description
CyberPower 5000VA Overview
The CyberPower PR5000LCDRTXL5U Smart App Sinewave UPS (5000VA / 4000W) features an LCD panel, offers a sine wave output, and is active-PFC-compatible for safeguarding mission-critical servers, telecom equipment and VoIP, and inter-networking hardware that requires seamless sine wave power. It incorporates microprocessor-based digital control and includes PowerPanel Business edition software. The UPS system is ENERGY STAR qualified with GreenPower UPS Bypass circuitry to reduce energy consumption and heat build-up.
Suitable for servers, workstations, network devices, and telecom equipment
Capacity of 5000VA / 4000W
Line-interactive topology
Full AVR (Automatic Voltage Regulation) Buck/Boost
Automatic Voltage Regulator automatically regulates low or high voltages to keep equipment working at safe AC power levels (220/230/240 VAC) without switching to battery
Can operate normally even during power problems such as short brownouts and blackouts
Sealed lead-acid batteries will provide power only if the incoming voltage drops below 131V or increases above 268V
GreenPower UPS
5 RU rackmount/tower convertible
Multi-function rotatable LCD
SNMP/HTTP remote management option
5 outlets / USB, serial, and EPO ports
PowerPanel Business edition software
EMI/RFI filtration
ENERGY STAR compliant and Active-PFC-compatible
UPC: 649532609451
Items Included
- CyberPower PR5000LCDRTXL5U Smart App Sinewave UPS (5000VA / 4000W)
- Front Panel
- 2 x Rackmount Ear (Stands)
- Rackmount Rails (1 Set - Left and Right Sides)
- 34 x Rackmount Ear and Rails Screw
- 8 x Screw Hole Dust Cover
- Limited 3-Year Manufacturer Warranty
Additional Resources
CyberPower 5000VA Specs
General
| UPS Topology |
Line-interactive
|
| Energy Saving |
GreenPower UPS bypass technology
|
Input
| Voltage |
208 to 240 VAC
|
| Input Frequency |
50Hz/60 Hz ± 3 Hz
|
| Voltage Range |
Input: 148 to 254 VAC
Adjustable: 131 to 268 VAC |
| Plug Type |
NEMA L6-30P
|
| Cold Start |
Yes
|
| Plug Style |
Straight
|
| Cord Length |
10' / 3 m
|
Output
| VA |
5000
|
| Watts |
4000
|
| Automatic Voltage Regulation (AVR) |
Yes
|
| On Battery Voltage |
208 VAC ± 5%
|
| On Battery Frequency |
60Hz ± 0.1%
|
| On Battery Waveform |
Sine wave
|
| Outlets |
Total: 5
Battery & Surge Protected: 3 Critical Load: 2 |
| Outlet Type |
3 x NEMA L6-30R, 2 x NEMA L6-20R
|
| Overload Protection |
On Utility: Circuit breaker
On Battery: Internal current limiting |
| Transfer time |
4 ms
|
Battery
| Runtime |
32 minutes at half load
13 minutes at full load |
| Battery Type |
Sealed lead-acid
|
| Battery Size |
12 V / 9 Ah
|
| Hot Swappable |
Yes
|
| Replacement Battery |
RB1290X16
|
| User Replaceable |
Yes
|
| Battery Quantity |
16
|
| Typical Recharge Time |
8 hours
|
| External Battery Compatibility |
Optional BPL48V75ART2U
|
Surge Protection / Filtering
| Surge Suppression |
2430 joules
|
| Phone RJ11 / Ethernet RJ45 |
1-In, 1-Out (combo)
|
Management and Communications
| LCD |
Multifunction LCD Panel
Displays: Load/Current Level, Runtime, Battery Level, Temperature (F & C), Battery In Use, Input Voltage, Output Voltage, Output Frequency, Overload, Wiring Fault, Battery Shutdown Voltage, Static Frequency Tolerance, Slew Rate, Silent Mode, Normal Mode |
| HID Compliant USB Port |
Yes
|
| Serial Port |
Yes (2x)
|
| EPO Port |
Yes
|
| Dry Contact Switch |
Yes
|
| LED Indicators |
Power On
|
| Alarms |
Audible: On Battery, Low Battery, Overload
|
| Management Features |
On-Device Management Features: Self-Test, Auto-Charge, Auto-Restart
|
| Software |
PowerPanel Business edition
|
| SNMP/HTTP Remote Monitoring |
Yes, with optional RMCARD202, RMCARD203 or RMCARD205
|
Environmental
| Operating Temperature |
32 to 104°F / 0 to 40°C
|
| Operating Relative Humidity |
0 to 95% non-condensing
|
| Storage Temperature |
5 to 113°F / -15 to 45°C
|
| Maximum Operating Elevation |
10,000' (0 to 3000 m)
|
| Maximum Storage Elevation |
50,000' / 0 to 15,000 m
|
Certifications
| Safety |
FCC Class A certified, UL 1778
CSA C22.2 No. 107.3-05 |
| Environmental |
RoHS compliant
|
Physical
| Rack Size |
5 RU
|
| Form Factor |
Rack
|
| Dimensions |
17 x 8.75 x 24.25" / 431.8 x 222.25 x 615.95 mm
|
| Weight |
222 lb / 100.69 kg
|
Packaging Info
| Package Weight |
283 lb
|
| Box Dimensions (LxWxH) |
35 x 24 x 14"
|
