CyberPower OR1000PFC Overview
The OR1000PFCLCD PFC Sinewave UPS from CyberPower is a mini-tower device with line-interactive topology that provides surge protection and battery backup via sinewave output for department servers, workgroup servers, workstations, network devices, telecom installations, and high-end audio/video equipment requiring PFC power source compatibility. It comes equipped with an output capacity of 1000 VA / 700W, features an input voltage range of 78-142 VAC to help correct minor power fluctuations without switching to battery power, which helps extend battery life and is useful in area where power fluctuations occur, and also has integrated circuitry for EMI/RFI filters. This UPS provides an integrated LCD panel for displaying immediate and detailed information on the UPS battery and power conditions, alerting users to potential problems before they can affect critical equipment and cause downtime.
When running with a full load, this UPS can power devices for up to 6.5 minutes. When running with a half load of 300W, it can power devices for up to 17.5 minutes. It can be recharged in around 8 hours and offers eight total NEMA 5-15R outlets that can absorb up to 1030 joules for keeping your devices safe against surges and spikes. To keep your devices powered during blackouts and brownouts, all eight outlets also provide battery power. Other connections offered are serial and USB Type-B.
This power supply is ENERGY STAR qualified with GreenPower UPS Bypass technology for reducing energy consumption and heat buildup to help save energy costs. Included with the power supply is the PowerPanel Business Edition UPS management software, which enables centralized power management, monitoring, control, and configuration. It also provides for the safe shutdown of connected servers, workstations, and other devices via a standard web browser or network management system (NMS), as well as allow admins to remotely manage each aspect of the UPS, facilitate the orderly automatic shutdown of connected equipment, prioritize outlets, and increase battery backup runtimes for the most critical equipment in the event of an extended power outage. This CyberPower UPS provides a limited lifetime connected equipment guarantee of up to $200,000, a limited 3-year product warranty and includes a USB Type-A to Type-B cable.
Supplies power long enough for equipment to properly shut down when utility power fails. Helps prevent loss of data and minimizes the component stress caused by a hard shutdown.
Diverts excess voltage away from sensitive electronic equipment during an AC power surge or power spike to help prevent damage.
Line Interactive Topology
Exists when a line interactive UPS has an auto-transformer that regulates low voltages, such as brownouts, and over voltages, such as spikes, without having to switch to its battery.
Automatic Voltage Regulation (AVR)
Provides clean, consistent AC power by automatically increasing (boosting) low voltage without using battery power when incoming utility power experiences minor fluctuations.
Provides power protection to ENERGY STAR 6.0 systems with Active PFC power supplies.
GreenPower UPS Bypass Design
This is a patented design that allows utility power to bypass the UPS transformer when AC power is stable, which helps reduce energy consumption, noise, and heat buildup.
Helps prevent electromagnetic and radio frequency interference to ensure clean power for connected equipment.
Displays immediate, detailed information on the UPS battery and power conditions, alerting users to potential problems before they can affect critical equipment and cause downtime.
Identifies when the unit is running on battery power, has overloaded, or has a low battery.
Resettable Circuit Breaker
Interrupts an electric current in a circuit when the current becomes too high.
Helps minimizes noise during operation for a quieter work environment.
Industrial-Grade Metal Housing
Helps prolongs unit life with rugged casing made of impact-resistant material for greater durability.
PowerPanel Business Edition Software
Provides IT professionals with tools for monitoring and managing the UPS and backup power. This software offers remote management functionality.
CyberPower will repair or replace a defective UPS system (including batteries) within three years of the purchase date.
Connected Equipment Guarantee
CyberPower will repair or replace properly connected equipment if it is damaged by a power surge.
![]()
UPC: 649532618569
In the Box
- CyberPower OR1000PFCLCD PFC Sinewave UPS
- Serial Cable
- USB Type-A to Type-B Cable
- PowerPanel Business Edition Software CD
- Limited Lifetime $200,000 Connected Equipment Guarantee
- Limited 3-Year Warranty
CyberPower OR1000PFC Specs
General
| Total Outlets |
8 x NEMA 5-15R |
| Protected Outlets |
8 x NEMA 5-15R (Battery and Surge) |
| Plug Type |
NEMA 5-15P |
| USB Charging Ports |
None |
| SmartSlot Interface |
None |
| Coax Protection |
None |
| Data Line Protection |
None |
| Communications |
USB via Type-B
Serial via DE-9/DB-9 |
| Topology |
Line Interactive |
| Transfer Time |
4 ms |
Power
| Surge Energy Rating |
1030 Joules |
| Maximum Wattage |
700 W |
| Nominal Input Voltage |
120 VAC |
| Input Voltage Range |
78 to 142 VAC |
| Input Frequency |
50/60 Hz ± 3 Hz (Auto Sensing) |
| Nominal Output Voltage |
120 VAC |
| Output Frequency |
50/60 Hz ± 1% |
| Load Capacity |
1000 VA |
| Waveform |
Sine Wave |
Battery
| Battery Capacity |
102 VAh |
| Chemistry |
Lead-Acid |
| Full-Load Runtime |
6.5 Minutes |
| Half-Load Runtime |
17.5 Minutes |
| Recharge Time |
8 Hours |
| User Replaceable |
Yes |
| Replacement Battery |
Not specified by manufacturer |
| Hot-Swap Support |
No |
| External Battery Connection |
None |
Environmental
| Operating Temperature |
32 to 104°F / 0 to 40°C |
| Operating Humidity |
0 to 90% |
| Storage Temperature |
5 to 113°F / -15 to 45°C |
| Operating Altitude |
50,000' / 15,240 m |
| Storage Altitude |
9843' / 3000 m |
Physical
| Cable Length |
6' / 1.83 m |
| Material of Construction |
Metal |
| Rackmount Size |
None |
| Dimensions (W x H x D) |
5.4 x 6.4 x 13.8" / 13.72 x 16.26 x 35.05 cm |
| Weight |
24.7 lb / 11.2 kg |
Packaging Info
| Package Weight |
28.95 lb |
| Box Dimensions (LxWxH) |
18.6 x 11 x 10.3" |
