| ₹ 114675.0 includes GST and import duties. | |
| B2B customers can avail ₹ 17487.94 ITC on this product | |
| 100% Secure Payments | 100% Genuine product | |
| The product is eligible for Free Shipping |
Description
The Smart App Intelligent LCD Series OR2200LCDRT2U UPS is designed to protect office servers, corporate and departmental networks, and network-based appliances. This ENERGY STAR� qualified UPS uses patented GreenPower UPS� Bypass circuitry that saves on energy costs by reducing energy consumption and heat buildup.
The OR2200LCDRT2U has a capacity of 2000VA/1320 Watts, 8 battery & surge protected NEMA 5-20R receptacles. This UPS has maintenance-free, user-replaceable batteries. The rotatable front LCD panel displays all major UPS vitals for ease of use. The UPS offers options for connectivity via 1 HID USB, 2 DB9 serial and a SNMP card slot (optional RMCARD202/203). Protection for phone/network (RJ11/RJ45) and cable/coax (RG-6) is included. EMI/RFI filters increase the immunity of the load to noise disturbances.
PowerPanel� Business Edition UPS Management software, Three-Year Warranty, and $300,000 Connected Equipment Guarantee are included.
- Smart App Intelligent LCD OR2200LCDRT2U 2200VA UPS LCD RT
- PowerPanel Business Edition Software
- User Manual
- USB Cable
- Serial Cable
- Registration Card
- 3 Year Limited Warranty
| Technical Information | |
|---|---|
| Plug/Connector Type | NEMA 5-20P |
| Receptacles | 8 x NEMA 5-20R |
| Dataline Protection | RJ-11 RJ-45 |
| Protection Type | EMI / RFI Overload Surge |
| Cord Length | 10 ft |
| Power Description | |
|---|---|
| Load Capacity (VA) | 2000 VA |
| Load Capacity (Watt) | 1320 W |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Waveform Type | Simulated Sine Wave |
| Circuit Breaker | Yes |
| Management | |
|---|---|
| Network Management | SNMP Manageable |
| Alarm | Battery Missing Fault Low Battery On Battery Overload |
| Controls/Indicators | |
|---|---|
| Status Indicators |
|
| Interfaces/Ports | |
|---|---|
| Serial Port | Yes |
| Modem (RJ-11) | Yes |
| Network (RJ-45) | Yes |
| USB | Yes |
| Battery Information | |
|---|---|
| Number of Batteries | 4 |
| Battery Chemistry | Sealed Lead Acid |
| Backup/Run Time (Full Load) | 4.80 Minute |
| Backup/Run Time (Half Load) | 13.20 Minute |
| Maximum Battery Recharge Time | 8 Hour |
| Physical Characteristics | |
|---|---|
| Height | 3.5" |
| Width | 17.5" |
| Depth | 15.8" |
| Form Factor | Tower/Rack Mountable |
| Weight (Approximate) | 52.70 lb |
| Miscellaneous | |
|---|---|
| Certifications & Standards |
|
| Software Included | PowerPanel Business Edition UPS Management |
| Environmentally Friendly | Yes |
| Environmental Certification | ENERGY STAR RoHS |
Bulk Discount
| Quantity | Price |
| 2 | ₹ 112381.5 |
| 3-5 | ₹ 111234.75 |
| 5-10 | ₹ 108941.25 |
| 10+ | ₹ 106647.75 |
Bulk discount will be automatically applied during checkout based on quantity.
