| ₹ 5801.0 includes GST and import duties. | |
| B2B customers can avail ₹ 884.65 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
PYBE30-Q48-S5H-DIN is a PYBE30 series high efficiency isolated DC/DC converter with heatsink. It is housed in a compact DIN rail package designed for easy installation in control cabinets. Supporting a 4:1 input range, single regulated output, and an operating temperature range of -40 to +85°C, this is encapsulated, DIN rail DC/DC converter provide a rugged solution for use in harsh environments including factory automation and industrial control applications. It includes over voltage, over current, short circuit protection. Safety approvals are certified to 62368-1: EN, BS EN, certified to 60950: UL.
- 48VDC typical input voltage, 5VDC output voltage
- 0 to 6000mA output current range, 30W maximum output power
- 87% typical efficiency (measured at nominal input voltage, full load)
- Industry standard pin-out, 1500VDC isolation
- 300KHz typical switching frequency (PWM mode)
- Aluminium alloy case material
- 2 years limited warranty
- Dimension is 76.00 x 31.50 x 29.90mm
Product details
Other details
| Brand | CUI |
| Part Number | PYBE30-Q48-S5H-DIN |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 5684.98 |
| 3-5 | ₹ 5626.97 |
| 5-10 | ₹ 5510.95 |
| 10+ | ₹ 5394.93 |
Bulk discount will be automatically applied during checkout based on quantity.
