| ₹ 5009.54 includes GST and import duties. | |
| B2B customers can avail ₹ 763.95 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
PYBE30-Q48-S12H-T is a PYBE30 series high efficiency isolated DC/DC converter with heatsink. Supporting a 4:1 input range, single regulated output, and an operating temperature range of -40 to +85°C, it provides provide a rugged solution for use in harsh environments including factory automation and industrial control applications. It includes over voltage, over current, short circuit protection. Safety approvals are certified to 62368-1: EN, BS EN, certified to 60950: UL.
- 48VDC typical input voltage, 12VDC output voltage
- 0 to 2500mA output current range, 30W maximum output power
- 88% typical efficiency (measured at nominal input voltage, full load)
- Industry standard pin-out, 1500VDC isolation
- 300KHz typical switching frequency (PWM mode)
- Aluminium alloy case material
- 2 years limited warranty
- Dimension is 76.00 x 31.50 x 25.30mm
Product details
Other details
| Brand | CUI |
| Part Number | PYBE30-Q48-S12H-T |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 4909.35 |
| 3-5 | ₹ 4859.25 |
| 5-10 | ₹ 4759.06 |
| 10+ | ₹ 4658.87 |
Bulk discount will be automatically applied during checkout based on quantity.
