PDRD-120-24 is a PDRD-120 series AC-DC power supply housed in a compact, DIN rail package designed for easy installation in control cabinets. It features over-temperature, output over-voltage, over-current, short-circuit protections, this DIN rail ac-dc power supply provides a rugged solution for use in industrial environments including factory automation and control applications. Certified to 61010-1: UL, certified to 62368-1: UL, EN, BS EN and designed to meet 60335-2-29: EN, 61558-2-16: EN, 4943.1: GB.
- Input voltage range from 85 to 305VAC, 120 to 430VDC, typ output voltage is 24VDC
- 5A maximum output current, 120W maximum output power, 90% typ efficiency
- CISPR32/EN55032 CLASS B compliant
- Constant current short-circuit protection and over-current protection
- Output voltage trim, accepts AC or DC input (dual use of the same terminal)
- 150KHz typ switching frequency, 4000VAC min isolation voltage (input to output for 1 min, 10mA max)
- Metal (AL1100, SGCC) material
- Dimension is 125 x 87.50 x 32mm
- Operating temperature range from -40 to 85°C
Product details
| Power Supply Applications:
ITE, Household & Laboratory Equipment
|
| No. of Outputs:
1 Output
|
| Output Power Max:
120W
|
| Output Voltage - Output 1:
24VDC
|
| Output Current - Output 1:
5A
|
| Output Voltage - Output 2:
-
|
| Output Current - Output 2:
-
|
| Output Voltage - Output 3:
-
|
| Output Current - Output 3:
-
|
| Output Voltage - Output 4:
-
|
| Output Current - Output 4:
-
|
| Input Voltage VAC:
85V AC to 305V AC
|
| Power Supply Output Type:
Fixed
|
| Product Range:
PDRD-120 Series
|
Other details
| Brand |
CUI |
| Part Number |
PDRD-120-24 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
