The Cree XLamp High-Current LED Array family is optimized for best?in?class lumen output, efficacy and reliability at high drive currents. XLamp CMT LEDs deliver performance in industry-compatible packages and LESes, enabling lighting manufacturers to upgrade their designs for applications such as track, downlight and outdoor lighting.
- 22mm optical source
- Forward voltage option: 36V class
- 85°C binning and characterization
- Maximum drive current: 750mA
- 115° viewing angle, uniform chromaticity profile
- Top-side solder connections
- RoHS and REACh compliant
- UL recognized component (E349212)
Applications
LED Lighting
Product details
| COB Colour |
Neutral White |
| Color Rendering Index Max |
73 |
| Power Rating |
181W |
| Luminous Flux @ Test |
13249lm |
| Forward Current @ Test |
1.6A |
| Viewing Angle |
115° |
| Forward Voltage VF Typ |
51.2V |
| Nominal CCT (K) |
4000 K |
| COB Length |
28mm |
| COB Width |
28mm |
| Opto Case Style |
SMD-2, No Lead |
| Lumens / Watt @ Current Test |
161.73lm/W |
| Light Emitting Surface |
22mm |
| Lens Type |
- |
| Lens Shape |
Round with Flat Top |
| Height |
1.45mm |
| Product Range |
XLamp CMT2890 Series |
| RoHS Phthalates Compliant |
To Be Advised |
Other details
| Brand |
CREE |
| Part Number |
CMT2890-0000-000P0B0A40E |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
