Description
Core SWX CXV-TA-VRAP Overview
- 1Description
- 2Compatibility
- 3Sharkfin Design
- 4Hot Swappable
- 5Parallel Discharge
- 6D-Tap Outputs
- 7Sliding Design
The Gold mount Sharkfin Battery Plate from Core SWX enables you to continuously power any camera with a Gold mount battery plate, such as the RED V-RAPTOR cinema camera, using two Gold mount batteries. The sharkfin design mounts two batteries side by side, enabling you to remove a depleted battery while leaving the remaining battery connected, resulting in no camera downtime. This plate incorporates two D-Tap output ports for powering accessories.
The batteries can power the camera by discharging at the same time, or you can choose to discharge them one at a time and use the hot swap function. Since the ports on some cameras such as the RED V-RAPTOR are on the back, to prevent blocking them, the plate can slide away from the back of the camera to make room for your cables to plug in. Each D-Tap and power output to the camera is unregulated 11 to 17 VDC.
- Description
- Compatibility
- Sharkfin Design
- Hot Swappable
- Parallel Discharge
- D-Tap Outputs
- Sliding Design
Core SWX CXV-TA-VRAP Specs
| Power Input | Gold Mount: 11 to 17 VDC |
| Power Output | Gold Mount: 11 to 17 VDC D-Tap: 11 to 17 VDC at 7.2 A |
| Camera Power Method | Battery Plate Mount Type |
| Inputs/Outputs | 2 x D-Tap |
| Plate Front / Battery Mount | Gold Mount |
| Plate Rear Mount | Gold Mount Battery Plate |
| Number of Battery Bays | 2 |
| Hot-Swap Support | Yes |
| Material of Construction | Aluminum |
| Dimensions | 3.7 x 3.6 x 3.5" / 9.4 x 9.1 x 8.9 cm |
| Weight | 1.2 lb / 544 g |
| Package Weight | 1.285 lb |
| Box Dimensions (LxWxH) | 8.3 x 6.6 x 3.9" |
