| ₹ 22560.0 includes GST and import duties. | |
| B2B customers can avail ₹ 3440.4 ITC on this product | |
| 100% Secure Payments | 100% Genuine product | |
| The product is eligible for Free Shipping |
Description
Cooler Master V750 SFX Gold ATX 3.1 Specs
Key Specs
| Total Connectors |
1x 24-Pin ATX Motherboard
Show More
1x 4+4-Pin EPS CPU 1x 8-Pin EPS CPU 4x 6+2-Pin PCIe 4x 4-Pin Peripheral / Molex 8x 15-Pin SATA |
| Cable Design |
Modular
|
| Total Wattage |
750 W
|
| Number of +12 V Rails |
1
|
| Efficiency Rating |
80 PLUS Gold
|
| Form Factor |
ATX
|
Connectivity
| Total Connectors |
1x 24-Pin ATX Motherboard
1x 4+4-Pin EPS CPU 1x 8-Pin EPS CPU 4x 6+2-Pin PCIe 4x 4-Pin Peripheral / Molex 8x 15-Pin SATA |
| Cable Design |
Modular
|
| PCIe Connector Distances |
15.7" / 400 mm
20.5" / 520 mm |
| SATA Connector Distances |
3.9" / 100 mm
8.5" / 215 mm 13" / 330 mm 17.5" / 445 mm |
| Peripheral Connector Distances |
3.9" / 100 mm
8.5" / 215 mm 13" / 330 mm 17.5" / 445 mm |
| ATX Connector Distance |
11.8" / 300 mm
|
| EPS Connector Distances |
17.7" / 450 mm
|
Electrical
| Total Wattage |
750 W
|
| Number of +12 V Rails |
1
|
| Combined Power for +12 V |
750 W
|
| Max Load for +12 V |
62.5 A
|
| Combined Power for +3.3/+5 V |
120 W
|
| Max Load for +3.3 V |
20 A
|
| Max Load for +5 V |
20 A
|
| Max Power for +5 Vsb |
15 W
|
| Max Load for +5 Vsb |
3 A
|
| Max Power for -12 V |
3.6 W
|
| Max Load for -12 V |
0.3 A
|
| Input Power |
100 to 240 VAC, 50 / 60 Hz
|
General
| Efficiency Rating |
80 PLUS Gold
|
| Active Power Factor Correction |
Yes
|
| Efficiency |
90%
|
Cooling
| Fan Size |
92 mm
|
| Bearing Type |
Fluid Dynamic Bearings (FDB)
|
Physical
| Form Factor |
ATX
|
| Compliance |
ATX v3.1
|
| Protection |
Over-Power Protection, Over-Temperature Protection, Over-Voltage Protection, Short-Circuit Protection, Surge and Inrush Protection, Under-Voltage Protection
|
| Certifications |
BSMI, CB, CCC, CE, EAC, FCC, RCM, TUV, UKCA, cTUVus
|
| Dimensions |
4.9 x 3.9 x 2.5" / 125 x 100 x 63.5 mm
|
| Weight |
3.13 lb / 1.42 kg
|
No additional resources available
All product and company names are trademarks or registered trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 22108.8 |
| 3-5 | ₹ 21883.2 |
| 5-10 | ₹ 21432.0 |
| 10+ | ₹ 20980.8 |
Bulk discount will be automatically applied during checkout based on quantity.
