Description
Comprehensive CHE-HDBT3010K Overview
Extend HDMI 4K60, audio, LAN, IR, and RS-232 signals over a single UTP cable up to 330' over Cat 6/6A with this Pro AV/IT Integrator Series HDBaseT 3.0 HDMI 4K60 4:4:4 Extender Kit from Comprehensive. Supporting 18 Gb/s HDBaseT 3.0, it can transmit video resolutions up to UHD 4K60 YUV 4:4:4, ensuring exceptional visual clarity and detail. The transmitter unit is equipped with HDMI input and audio de-embedding functionality, while the receiver unit features HDMI output and audio de-embedding capabilities. The transmitter offers the flexibility to switch between HDBT standard mode (default) and HDBT long-reach mode, allowing for optimized performance. This extender also features a bidirectional POC (Power over Cable) function, providing power to both the transmitter and receiver units and eliminating the need for additional power supplies.
In the Box
- Comprehensive Pro AV/IT Integrator Series HDBaseT 3.0 HDMI 4K60 4:4:4 Extender Kit (330')
- Limited 3-Year Manufacturer Warranty
Additional Resources
Comprehensive CHE-HDBT3010KSpecs
| Inputs |
1x HDMI (HDMI 2.0b)
|
| Embedded Audio Input |
HDMI
|
| Outputs |
1x RJ45 (HDBaseT)
1x 1/8" / 3.5 mm TRS (Stereo Audio) |
| Transmitter Other I/O |
1x 1/8" / 3.5 mm IR Input
1x 1/8" / 3.5 mm IR Output 1x USB-B Host 1x Block 3-Pin RS-232 1x Micro-USB Update 2x USB-A Device |
| Inputs |
1x RJ45 (HDBaseT)
|
| Outputs |
1x HDMI (HDMI 2.0b)
1x 1/8" / 3.5 mm TRS (Stereo Audio) |
| Receiver Other I/O |
1x 1/8" / 3.5 mm IR Input
1x 1/8" / 3.5 mm IR Output 1x Block 3-Pin RS-232 2x USB-A Device 1x Micro-USB Update |
| HDR Support |
Yes, HDR10/HDR10+/Hybrid Log Gamma
|
| HDCP Support |
Yes, Version 2.2
|
| EDID Support |
Yes
|
| Max Transmission Distance |
UHD 4K at 60 Hz:
328' / 100 m (via Cat 6a/7) 1080p: 492' / 150 m (via Cat 6/6a/7) |
| Video Format |
HDMI (8/10/12-Bit 4:4:4/4:2:2/4:2:0 RGB, YCC)
UHD 4K: 60 fps |
| DTS Compatibility |
DTS, DTS 96/24, DTS Express, DTS-HD High Resolution, DTS-HD Master Audio
|
| Dolby Compatibility |
Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby TrueHD
|
| Supported Cable Types |
Cat 6/6a/7 UTP
|
| Transmitter Power I/O |
1x Barrel (24 VDC at 1 A) Input
|
| Receiver Power I/O |
1x Barrel (24 VDC at 1 A) Input
|
| PoE Support |
PoE Proprietary
|
| Transmitter Power Consumption |
Device: 24 VDC at 1 A (14.28 W)
Power Supply: 100 to 240 VAC |
| Receiver Power Consumption |
Device: (14.28 W)
Power Supply: 100 to 240 VAC |
| Certifications |
CE, FCC, UL
|
| Operating Conditions |
32 to 104°F / 0 to 40°C at 20 to 90% Humidity
|
| Storage Conditions |
-4 to 140°F / -20 to 60°C
|
| Transmitter Dimensions |
5.7 x 3.1 x 0.9" / 144 x 78 x 23 mm
|
| Receiver Dimensions |
5.7 x 3.1 x 0.9" / 144 x 78 x 23 mm
|
| Transmitter Weight |
11.4 oz / 323 g
|
| Receiver Weight |
11.3 oz / 319 g
|
| Package Weight |
2.35 lb
|
| Box Dimensions (LxWxH) |
10.3 x 7.4 x 3"
|
