Description
Comprehensive HDBTWP Overview
The Comprehensive Pro AV/IT HDBaseT 4K 18G Single-Gang HDMI,USB 2.0 and Audio Wall Plate Extender Kit< allows you to extend HDMI, USB, and audio signals up to 230'. It includes a wall plate transmitter and a receiver unit.
- Extend 4K HDMI, Audio and USB 2.0 High Speed Signals over a Single UTP Cable up to 230'
- Comprehensive's CHE-HDBTWP121K Wall Plate Extender kit was designed to extend HDMI, analog audio and high speed USB 2.0 signals up to 230ft over Cat5e or Cat6 cables. Perfect for all commercial AV/IT installations that requires HDMI and USB 2.0 and audio inputs.
- Supports 4K HD Video up to 4K@60Hz (4:4:4)
- This versatile USB/HDMI extender can transmit 4K resolutions up to 4K@60Hz 4:4:4 up to 131' and 1080P@60Hz up to 230', making it perfect for classrooms, meeting rooms, huddle spaces and other AV installations.
- Supports Bi-directional POC (Power over Cable) Delivery
- The CHE-HDBTWP121K includes 24V POC function support. Either the TX or RX can be powered by the included 24V/1A power adapter or Phoenix jack.
- Dual USB 2.0 Ports
- The two high speed USB 2.0 ports allow you to connect two USB devices and use them simultaneously.
- Dedicated Analog Audio
- The 3.5mm analog audio jack delivers audio independent from the HDMI signal for additional audio routing.
- A Must Have Device for Every AV Space
- Ideal for use in court rooms, classrooms, conference rooms and anywhere audio-visual devices can be extended from a remotely located HDMI source device.
- Compatible with Promethean Interactive Whiteboard
- This USB extender supports and is fully compatible with the Promethean Interactive Whiteboard.
- Quality You Can Count On
- Since 1974, Comprehensive has been manufacturing the highest quality commercial grade solutions for AV and IT professionals. The CHE-HDBTWP121K extender kit continues that tradition with high end materials, components and quality control to ensure years of worry-free use.
UPC: 808447083675
In the Box
- Comprehensive Pro AV/IT HDBaseT 4K 18G Single-Gang HDMI,USB 2.0 and Audio Wall Plate Extender Kit (Up to 230')
- Decora Wall Plate
- 2 x 3-Pin Phoenix Connector
- 2-Pin Phoenix Connector
- Mounting Ear Kit
- 24 VDC Power Supply
- USB 2.0 Type-A to USB-B Cable
Comprehensive HDBTWP Specs
Transmitter Interfaces
| Inputs | 1 x HDMI (HDMI 1.4a) 1 x USB-B 1 x 1/8" / 3.5 mm TRS |
| Outputs | 1 x RJ45 (HDBaseT) |
| Transmitter Other I/O | 1 x Block 3-Pin RS-232 |
Receiver Interfaces
| Inputs | 1 x RJ45 (HDBaseT) |
| Outputs | 1 x HDMI (HDMI 1.4a) 1 x 1/8" / 3.5 mm TRS |
| Receiver Other I/O | 2 x USB-A 1 x Block 3-Pin RS-232 |
Standards
| HDCP Support | Version 2.2 |
| EDID Support | None |
Transmission
| Max Transmission Distance | 230' / 70.1 m |
| DTS Compatibility | DTS, DTS 96/24, DTS Express, DTS-HD High Resolution, DTS-HD Master Audio |
| Dolby Compatibility | Dolby TrueHD |
Power
| Receiver Power Connector | 1 x Barrel Input |
| Transmitter Power Consumption | Device: (9 W) |
| Receiver Power Consumption | Device: (9 W) |
General
| Transmitter Dimensions | 4 x 1.8 x 1.2" / 10.2 x 4.6 x 3 cm |
| Receiver Dimensions | 9 x 5.5 x 2.9" / 22.9 x 14 x 7.4 cm |
| Wall Box Gang Size | 1 Gang |
Comprehensive HDBTWP Reviews
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 70099.4 |
| 3-5 | ₹ 69384.1 |
| 5-10 | ₹ 67953.5 |
| 10+ | ₹ 66522.9 |
Bulk discount will be automatically applied during checkout based on quantity.
