Product details
| Inductance Tolerance |
± 20% |
| RMS Current (Irms) |
30A |
| Saturation Current (Isat) |
18A |
| Power Inductor Case |
19.18mm x 9.27mm x 12.95mm |
| Inductance |
4.7µH |
| Inductor Construction |
Shielded |
| Product Range |
SER2000 Series |
| DC Resistance Max |
0.00182ohm |
| Packaging |
Cut Tape |
Other details
| Brand |
COILCRAFT |
| Part Number |
SER2013-472MLD |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
