Product details
Inductance Tolerance |
± 20% |
RMS Current (Irms) |
1A |
Saturation Current (Isat) |
1.3A |
Power Inductor Case |
3.9mm x 3.9mm x 1.7mm |
Inductance |
6.8µH |
Inductor Construction |
Shielded |
Product Range |
LPS4018 Series |
DC Resistance Max |
0.15ohm |
Packaging |
Cut Tape |
Other details
Brand |
COILCRAFT |
Part Number |
LPS4018-682MRB |
Quantity |
Each (Supplied on Cut Tape) |
Technical Data Sheet EN |
|
