Product details
| Inductance Tolerance |
± 20% |
| RMS Current (Irms) |
550mA |
| Saturation Current (Isat) |
1A |
| Power Inductor Case |
3.9mm x 3.9mm x 1.1mm |
| Inductance |
10µH |
| Inductor Construction |
Shielded |
| Product Range |
LPS4012 Series |
| DC Resistance Max |
0.35ohm |
| Packaging |
Cut Tape |
Other details
| Brand |
COILCRAFT |
| Part Number |
LPS4012-103MRB |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
