Product details
| Inductance Tolerance |
� 20% |
| RMS Current (Irms) |
11.2A |
| Saturation Current (Isat) |
26.8A |
| Power Inductor Case |
22.35mm x 16.26mm x 12mm |
| Inductance |
3.9�H |
| Inductor Construction |
Unshielded |
| Product Range |
DO5040H Series |
| DC Resistance Max |
0.006ohm |
| Packaging |
Cut Tape |
Other details
| Brand |
COILCRAFT |
| Part Number |
DO5040H-392MLD |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
