CimaPro B-23 Overview
The B-23 Mini Tripod Ball Head from CimaPro is a compact ball head made of precision CNC-machined aluminum that has a load capacity of 11 pounds. The top plate has a standard 1/4-20" threaded stud for attaching a camera or other accessory, and it has a rubberized pad for added traction. The main control knob releases the ball and the panoramic base simultaneously for speedy adjustment and is knurled for easy gripping. The base has a 1/4"-20 threaded socket, allowing it to be attached to select tripods and other rigs for easy custom setups.
CimaPro B-23 Specs
Head
Head Type |
Ball Head |
Base Mount |
1/4"-20 Female |
Camera Mounting Screw |
1/4"-20 Male |
Quick Release Plate Type |
No Quick Release |
Number of Bubble Levels |
None |
Friction Control |
No |
Independent Pan Lock |
No |
Ball Sphere Diameter |
0.9" / 23 mm |
Pan & Tilt Range
Vertical Tilt |
90° |
Panning Range |
360° |
General
Load Capacity |
11 lb / 5 kg |
Weight |
3.5 oz / 100 g |
Packaging Info
Package Weight |
0.28 lb |
Box Dimensions (LxWxH) |
5.5 x 2.9 x 1.6" |
