Description
CHAUVET Professional 3 Quad Zoom Specs
Key Specs
| Fixture Type |
PAR
|
| Light Source |
7x Color LED - 13 W / 2.7
|
| Colors |
Blue, Green, Lime, Red (Wash)
|
| Beam Angle |
3.9 to 38.5?
|
| Control Protocols |
DMX512, RDM
|
| AC Input Power |
100 to 240 VAC, 50/60 Hz
|
| Power / Current Consumption |
120 VAC, 60 Hz: 258 W / 2.17 A
208 VAC, 60 Hz: 255 W / 1.28 A 230 VAC, 50 Hz: 260 W / 1.2 A |
| Mounting |
Dual/Scissor Yoke
|
Light
| Fixture Type |
PAR
|
| Light Source |
7x Color LED - 13 W / 2.7
|
| Expected Lamp Life |
50,000 Hours
|
| Colors |
Blue, Green, Lime, Red (Wash)
|
| Photometrics |
3.9?:
2560 fc / 27,567 Lux at 16.4' / 5 m 38.5?: 61 fc / 657 Lux at 16.4' / 5 m |
| Beam Angle |
3.9 to 38.5?
|
| Field Angle |
6 to 52.6?
|
| Shutter / Strobe |
Electronic
|
| Zoom Adjustment |
Motorized, 3.9 to 52.6?
|
| Dimming |
16-Bit Electronic with 4 Dimmer Modes
|
Performance
| Operating Modes |
Automatic, Color Change, Color Dimmer, DMX, Program, Standalone, Static Color
|
| Strobe Rate |
0 to 30 Hz
|
| Gobos |
No
|
Control
| Control Protocols |
DMX512, RDM
|
| DMX Channel Modes |
9 Mode(s):
1 / 5 / 7 / 11 / 12 / 13 / 16-Channel |
| Display / Controls |
OLED / 5-Button
|
| Remote Control |
No
|
| Mobile App Compatible |
No
|
Connectivity
| Inputs/Outputs |
1 x XLR 5-Pin DMX Input
1 x XLR 5-Pin DMX Output |
| Wireless |
No
|
Power
| AC Input Power |
100 to 240 VAC, 50/60 Hz
|
| AC Power Connector |
Input: 1x Seetronic IP-Rated
Output: 1x Seetronic IP-Rated Cord Length: 5' / 1.5 m |
| Fuse |
No
|
| Power / Current Consumption |
120 VAC, 60 Hz: 258 W / 2.17 A
208 VAC, 60 Hz: 255 W / 1.28 A 230 VAC, 50 Hz: 260 W / 1.2 A |
Physical
| Environmental Resistance |
Dust/Water-Resistant (IP65)
|
| Mounting |
Dual/Scissor Yoke
|
| Included Accessories |
1x Gel Frame
1x Power Cable |
| Duty Cycle |
No
|
| Exterior Color |
Black
|
| Max Housing Temperature |
122?F / 50?C
|
| Certifications |
CE, FCC, MET
|
| Dimensions |
16.34 x 10.94 x 8.3" / 41.5 x 27.79 x 21.1 cm
|
| Weight |
14.2 lb / 6.4 kg
|
Packaging Info
| Package Weight |
21.265 lb
|
| Box Dimensions (LxWxH) |
19.2 x 13.2 x 10.4"
|
Additional Resources
No additional resources available
