Description
Resonators function like crystals, but are a lower cost solution that does not require external caps.
Features & Specs
- Type: Ceramic
- Frequency: 16 MHz
- Frequency Stability: ±0.3%
- Frequency Tolerance: ±0.5%
- Capacitance: 15 pF
- Impedance: 40 Ohms
- Operating Temperature: -40°C ~ 85°C
- Mounting Type: Surface Mount
- Built in Capacitor
- Dimensions: 0.126" L x 0.051" W (3.20mm x 1.30mm)
- Height: 0.039" (1.00mm)
- Mfg Part #: CSTNE16M0V530000R0
Features & Specs
- Type: Ceramic
- Frequency: 16 MHz
- Frequency Stability: ±0.3%
- Frequency Tolerance: ±0.5%
- Capacitance: 15 pF
- Impedance: 40 Ohms
- Operating Temperature: -40°C ~ 85°C
- Mounting Type: Surface Mount
- Built in Capacitor
- Dimensions: 0.126" L x 0.051" W (3.20mm x 1.30mm)
- Height: 0.039" (1.00mm)
- Mfg Part #: CSTNE16M0V530000R0
Documentation
WARNING: This product may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. See link below for more information. www.P65Warnings.ca.gov
Bulk Discount
| Quantity | Price |
| 2 | ₹ 39.2 |
| 3-5 | ₹ 38.8 |
| 5-10 | ₹ 38.0 |
| 10+ | ₹ 37.2 |
Bulk discount will be automatically applied during checkout based on quantity.
